JPA多条件复杂SQL动态分页查询

概述

　　ORM映射为我们带来便利的同时，也失去了较大灵活性，如果SQL较复杂，要进行动态查询，那必定是一件头疼的事情（也可能是lz还没发现好的方法），记录下自己用的三种复杂查询方式。

环境

springBoot

IDEA2017.3.4

JDK8

pom.xml

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.1.6.RELEASE</version>
        <relativePath/> <!-- lookup parent from repository -->
    </parent>
    <groupId>com.xmlxy</groupId>
    <artifactId>seasgame</artifactId>
    <version>0.0.1-SNAPSHOT</version>
    <name>seasgame</name>
    <description>Demo project for Spring Boot</description>

    <properties>
        <java.version>1.8</java.version>
    </properties>

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>

        <!--数据库连接-->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-jpa</artifactId>
        </dependency>
        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
            <scope>runtime</scope>
        </dependency>

        <!-- 热启动等 -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-devtools</artifactId>
            <scope>runtime</scope>
            <optional>true</optional>
        </dependency>

        <!--Java bean 实体-->
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <optional>true</optional>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-jpa</artifactId>
        </dependency>

        <!--swagger2 API 测试工具 -->
        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger2</artifactId>
            <version>2.8.0</version>
        </dependency>
        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger-ui</artifactId>
            <version>2.8.0</version>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-configuration-processor</artifactId>
            <optional>true</optional>
        </dependency>
        <!--安全框架认证-->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-security</artifactId>
        </dependency>
        <dependency>
            <groupId>net.sf.json-lib</groupId>
            <artifactId>json-lib</artifactId>
            <version>2.2.2</version>
            <classifier>jdk15</classifier>
        </dependency>
        <!--汉字转拼音-->
        <dependency>
            <groupId>com.belerweb</groupId>
            <artifactId>pinyin4j</artifactId>
            <version>2.5.1</version>
        </dependency>
        <!-- thymeleaf模板 -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-thymeleaf</artifactId>
        </dependency>
        <!--
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        移除嵌入式tomcat插件
        <exclusions>
            <exclusion>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-starter-tomcat</artifactId>
            </exclusion>
        </exclusions>
    </dependency>
    -->

        <dependency>
            <groupId>javax.servlet</groupId>
            <artifactId>javax.servlet-api</artifactId>
            <version>3.1.0</version>
            <scope>provided</scope>
        </dependency>
    </dependencies>
    <packaging>war</packaging>
    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-compiler-plugin</artifactId>
                <configuration>
                    <source>1.8</source>
                    <target>1.8</target>
                </configuration>
            </plugin>
        </plugins>

        <finalName>seasgame</finalName>
        <pluginManagement>
            <plugins>
                <plugin>
                    <groupId>org.apache.maven.plugins</groupId>
                    <artifactId>maven-compiler-plugin</artifactId>
                    <version>2.3.2</version>
                    <configuration>
                        <encoding>${project.build.sourceEncoding}</encoding>
                        <source>1.7</source>
                        <target>1.7</target>
                    </configuration>
                </plugin>
                <plugin>
                    <groupId>org.apache.maven.plugins</groupId>
                    <artifactId>maven-surefire-plugin</artifactId>
                    <configuration>
                        <testFailureIgnore>true</testFailureIgnore>
                    </configuration>
                </plugin>
            </plugins>
        </pluginManagement>
    </build>

</project>

@Query

当一个SQL较为复杂时，第一个想到的就是原生的SQL语句。如果只是简单的查询，那情况还没这么糟糕

 @Query(value = " SELECT IFNULL(sum(right_num),0) sumRight FROM t_record WHERE record_owner_id = ?1 AND responder_no = ?2 ",nativeQuery = true)
 Map<String,Object> sumRightNum(int studentId,int responderNo);

但如果需要进行动态查询，或更改，那这个value就变得复杂了。

package com.xmlxy.seasgame.dao;

import com.xmlxy.seasgame.entity.ScoreEntity;
import org.springframework.data.jpa.repository.Modifying;
import org.springframework.data.jpa.repository.Query;
import org.springframework.data.repository.CrudRepository;
import org.springframework.data.repository.query.Param;
import org.springframework.transaction.annotation.Transactional;

import java.util.List;

/**
 *
 * Description:
 * @author hwc
 * @date 2019/9/5
 * @return
*/
public interface ScoreDao extends CrudRepository<ScoreEntity,Integer>
{

    /**
     *
     * Description:
     *@param scoreEntity
     * @author hwc
     * @date 2019/9/6
    */
    @Transactional(rollbackFor = Exception.class)
    @Modifying
    @Query(value = "UPDATE t_score t SET " +
            "t.responder_no = CASE WHEN :#{#scoreEntity.responderNo} IS NULL THEN t.responder_no ELSE :#{#scoreEntity.responderNo} END," +
            "t.max_level = CASE WHEN :#{#scoreEntity.maxLevel} IS NULL THEN t.max_level ELSE :#{#scoreEntity.maxLevel} END," +
            "t.right_num = CASE WHEN :#{#scoreEntity.rightNum} IS NULL THEN t.right_num ELSE :#{#scoreEntity.rightNum} END," +
            "t.use_time = CASE WHEN :#{#scoreEntity.userTime} IS NULL THEN t.use_time ELSE :#{#scoreEntity.userTime} END WHERE student_id = :#{#scoreEntity.getStudentId()}",nativeQuery = true)
    void updateScore(@Param("scoreEntity") ScoreEntity scoreEntity);
}

JPQL

如果Java代码内发出JPQL查询，就需要利用到EntityManager的响应方法了。一般执行以下流程

1. 获取一个EntityManager实例
2. 调用实例的方法createQuery，创建一个Query实例，如果有需要可以指定检索的最大数量和起始位置
3. 使用Query方法getResultList执行查询，当然更新和删除操作得使用executeUpdate执行

进行一个复杂的动态SQL查询

   public Page<RankEntity> getScoreByRank(int gradeId,int classId,Pageable pageable)
    {
        StringBuilder countSelectSql = new StringBuilder("");
        countSelectSql.append(" SELECT COUNT(*) ");
        countSelectSql.append(" FROM ");
        countSelectSql.append(" t_score s, ");
        countSelectSql.append(" t_student st   ");
        countSelectSql.append(" WHERE ");
        countSelectSql.append(" s.student_id = st.student_id ");

        StringBuilder selectSql = new StringBuilder();
        selectSql.append(" SELECT s.student_id,st.real_name,st.student_class,s.max_level,s.use_time,s.right_num ");
        selectSql.append(" FROM t_score s ");
        selectSql.append(" JOIN t_student st ON s.student_id = st.student_id ");
        selectSql.append(" WHERE 1 = 1 ");
        Map<String,Object> params = new HashMap<>();
        StringBuilder whereSql = new StringBuilder();
        if (gradeId != -1)
        {
            whereSql.append(" AND st.student_grade = :student_grade ");
            params.put("student_grade",gradeId);
        }
        /**班级ID*/
        if (classId != -1)
        {
            whereSql.append(" AND st.student_class = :classId ");
            params.put("classId",classId);
        }
        String orderSql = " ORDER BY s.max_level DESC,s.use_time,s.right_num ASC ";
        String countSql = new StringBuilder().append(countSelectSql).append(whereSql).toString();
        Query countQuery = entityManager.createNativeQuery(countSql);
        for (Map.Entry<String,Object> entry : params.entrySet())
        {
            countQuery.setParameter(entry.getKey(),entry.getValue());
        }
        BigInteger totalCount = (BigInteger)countQuery.getSingleResult();

        String querySql = new StringBuilder().append(selectSql).append(whereSql).append(orderSql).toString();

        Query query = entityManager.createNativeQuery(querySql,RankEntity.class);
        for (Map.Entry<String,Object> entry:params.entrySet())
        {
            query.setParameter(entry.getKey(),entry.getValue());
        }
        query.setFirstResult((int) pageable.getOffset());
        query.setMaxResults(pageable.getPageSize());

        List<RankEntity> rankEntities = query.getResultList();
        Page<RankEntity> page = new PageImpl<>(rankEntities,pageable,totalCount.longValue());
        return page;
    }

注意：如果没有重新定义Pageable那么pageNumber必须减1，因为是从0开始的。

Criteria

这是一种规范查询是以元模型的概念为基础的，这个元模型可以是实体累，嵌入类，或者映射的父类，简单介绍几个里面用到接口。

CriteraQuery是一个特定的顶层查询对象，里面包含select，from，where，order by等各个部分，然而他只对实体类或嵌入类的标准查询起作用。

Root标准查询的根对象，根定义了实体类型，是你想要查询要获得的结果，也可以添加查询条件，结合实体管理对象得到查询的对象。

CriteriaBuilder接口用来构建CritiaQuery的构建器

StudentEntity类

package com.xmlxy.seasgame.entity;

import io.swagger.annotations.ApiModel;
import lombok.Data;

import javax.persistence.*;
import javax.print.attribute.standard.MediaSize;
import java.io.Serializable;

/**
 *
 * Description:学生对象
 * @param
 * @author hwc
 * @date 2019/8/8
*/
@Entity
@Table(name = "t_base_student")
@ApiModel
@Data
public class StudentEntity implements Serializable
{
    private static final long serialVersionUID = 546L;
    @Id
    @GeneratedValue(strategy = GenerationType.AUTO)
    @Column(name = "student_id")
    private Integer studentId;

    @Column(name = "student_grade")
    private Integer studentGrade;

    @Column(name = "student_class")
    private Integer studentClass;

    @Column(name = "address")
    private String address;

    @Column(name = "telephone")
    private Integer telephone;

    @Column(name = "real_name")
    private String realName;

    @Column(name = "id_number")
    private String idNumber;

    @Column(name = "study_id")
    private String studyId;

    @Column(name = "is_delete")
    private int isDelete;

    @Column(name = "uuid")
    private String uuid;

}

dao层

public interface StudentDao extends JpaRepository<StudentEntity,Integer>,JpaSpecificationExecutor
{
}

动态查询

    public Page<StudentEntity> getTeacherClassStudent(int pageNumber,int pageSize,int gradeId, int classId,String keyword)
    {
        pageNumber = pageNumber < 0 ? 0 : pageNumber;
        pageSize = pageSize < 0 ? 10 : pageSize;
        Specification<StudentEntity> specification = new Specification<StudentEntity>()
        {
            @Override
            public Predicate toPredicate(Root<StudentEntity> root, CriteriaQuery<?> criteriaQuery, CriteriaBuilder criteriaBuilder)
            {
                //page : 0 开始, limit : 默认为 10
                List<Predicate> predicates = new ArrayList<>();
                predicates.add(criteriaBuilder.equal(root.get("studentGrade"),gradeId));
                predicates.add(criteriaBuilder.equal(root.get("studentClass"),classId));
                if (!Constant.isEmptyString(keyword))
                {
                    predicates.add(criteriaBuilder.like(root.get("realName").as(String.class),"%" + keyword + "%"));
                }
                return criteriaBuilder.and(predicates.toArray(new Predicate[predicates.size()]));
            }
        };
        /*studentId必须是实体类属性与数据库对应，否则报ropertyReferenceException异常*/
        PageRequest page = new PageRequest(pageNumber,pageSize,Sort.Direction.ASC,"studentId");
        Page<StudentEntity> pages = studentDao.findAll(specification,page);
        return pages;
    }

因为这个项目应用比较简单，所以条件只有一个，如果条件较多，甚至可以定义一个专门的类去接收拼接参数，然后判断，成立就add进去。

转载一篇写得不错的文章：https://blog.csdn.net/u010775025/article/details/80497986
