powerdesigner将name的名字赋给comment

1 PowerDesigner中批量根据对象的name生成comment的脚本

执行方法：Open PDM -- Tools -- Execute Commands -- Run Script

Vb script代码
Option Explicit
ValidationMode = True
InteractiveMode = im_Batch

Dim mdl 'the current model

'get the current active model
Set mdl = ActiveModel
If (mdl Is Nothing) Then
MsgBox "There is no current Model"
ElseIf Not mdl.IsKindOf(PdPDM.cls_Model) Then
MsgBox "The current model is not an Physical Data model."
Else
ProcessFolder mdl
End If

'This routine copy name into code for each table, each column and each view
'of the current folder
Private sub ProcessFolder(folder)
Dim Tab 'running table
for each Tab in folder.tables
if not tab.isShortcut then
tab.comment = tab.name
Dim col 'running column
for each col in tab.columns
col.comment= col.name
next
end if
next

Dim view 'running view
for each view in folder.Views
if not view.isShortcut then
view.comment = view.name
end if
next

'go into the sub-packages
Dim f 'running folder
For Each f In folder.Packages
if not f.IsShortcut then
ProcessFolder f
end if
Next
end sub
