Edit Values
Mars II µarch
General Info
Arch Type	CPU
Designer	Phytium
Manufacturer	TSMC
Introduction	2019
Process	16 nm
Core Configs	64
Pipeline
Type	Superscalar, Pipelined
OoOE	Yes
Speculative	Yes
Reg Renaming	Yes
Instructions
ISA	ARMv8
Succession
Mars I

Mars II is the successor to Mars I, an ARM server SoC microarchitecture designed by Phytium Technology for the Chinese server market.

contents

[hide]

• 1Process technology
• 2Architecture
  • 2.1Key changes from Mars I
• 3Block diagram
  • 3.1Entire SoC
  • 3.2Panel
  • 3.3Core
• 4Overview
• 5Package
• 6Die
  • 6.1Panel
  • 6.2SoC
• 7All Mars II Processors
• 8Bibliography

Process technology[edit]



Mars II is largely a shrink of Mars I, from 28 nm process to a 16 nm FinFET process.

Architecture[edit]

Key changes from Mars I[edit]

• 16 nm process (from 28 nm)
• 15% higher frequency (2.3 GHz, up from 2 GHz)
  • higher FLOPS performance (588.8 GFLOPS, up from 512 GFLOPS)
• -25% lower power (96 W TDP, down from 120 W)
• Core
  • FTC-662 (from FTC-661/0)
• System memory
  • Panel directly connected to 1 MCU (Previously linked to CMC)
    • DDR4 (from DDR3)
    • Higher data rates (2400 MT/s, up from 1600 MT/s)

This list is incomplete; you can help by expanding it.

Block diagram[edit]

Entire SoC[edit]

Panel[edit]

Core[edit]

Main article: Xiaomi Core

See Xiaomi Core.

Overview[edit]

Mars II is Phytium's second-generation many-core server processor based on a custom ARM core. The Mars II is largely a shrink of their first-generation SoC but it does introduce a number of enhancements. Fabricated on a leading-edge 16 nm FinFET process, the new SoC is considerably smaller than the prior die, offers higher frequency, and lower power. Mars II features 64 custom ARMv8.0 cores operating at up to 2.3 GHz for a total of 588.8 GFLOPS. The SoC incorporates high DDR4-2400 memory channels and includes 33 PCIe Gen 3.0 lanes.

Package[edit]

Package	FCBGA-3576
Dimensions	61mm x 61mm
Bumps	11916
Contacts	3576

Die[edit]

Panel[edit]



SoC[edit]

• 16 nm process (16FF+) GL
• 1 Poly, 11 Metal layers, RDL
• 6,000,000,000 transistors
• 370 mm² die size
• 2.3 GHz @ 0.9 V, 96 W

All Mars II Processors[edit]

	List of Mars II-based Processors
Model	Launched	Cores	L2	Frequency	TDP
FT-2000+/64	2019	64	32 MiB	2.3 GHz	96 W
Count: 1

Bibliography[edit]

• HPC Asia 2019
