Redis Stream消息队列

工具类部分内容

package com.hwd.campus.common.redis.utils;

import com.hwd.campus.common.redis.constant.RedisKeyPrefixConst;
import com.hwd.campus.common.redis.service.RedisListSelect;
import com.hwd.campus.common.redis.service.RedisSelect;
import lombok.AllArgsConstructor;
import org.springframework.data.redis.connection.stream.Record;
import org.springframework.data.redis.connection.stream.StreamInfo;
import org.springframework.data.redis.core.*;
import org.springframework.stereotype.Component;

import java.util.*;
import java.util.concurrent.ThreadLocalRandom;
import java.util.concurrent.TimeUnit;
import java.util.stream.Collectors;

/**
 * @author
 * @datetime 2023-01-11 09:25:52
 * @description
 */
@Component
@AllArgsConstructor
public class RedisUtils {

    private RedisTemplate<String, Object> redisTemplate;
    private StringRedisTemplate stringRedisTemplate;
    private static final Long DAY_SECONDS = 60 * 60 * 24L;
    private static final Long SEVEN_DAY_SECONDS = 7 * DAY_SECONDS;

    public StreamInfo.XInfoGroups groups(String key) {
        return stringRedisTemplate.opsForStream().groups(key);
    }

    public void addGroup(String key, String groupName) {
        stringRedisTemplate.opsForStream().createGroup(key, groupName);
    }

    /**
     * 添加流
     *
     * @param streamKey  流关键
     * @param msgContext 上下文
     */
    public void addStream(String streamKey, Object msgContext) {
        stringRedisTemplate.opsForStream().add(Record.of(msgContext).withStreamKey(streamKey));
    }
}

此处采用Stream实现消息队列

创建监听器

package com.hwd.campus.manage.biz.listener;

import com.hwd.campus.common.redis.constant.RedisKeyPrefixConst;
import com.hwd.campus.common.redis.utils.RedisUtils;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.DisposableBean;
import org.springframework.boot.ApplicationArguments;
import org.springframework.boot.ApplicationRunner;
import org.springframework.data.redis.connection.RedisConnectionFactory;
import org.springframework.data.redis.connection.stream.*;
import org.springframework.data.redis.serializer.StringRedisSerializer;
import org.springframework.data.redis.stream.StreamMessageListenerContainer;
import org.springframework.scheduling.concurrent.ThreadPoolTaskExecutor;
import org.springframework.stereotype.Component;

import javax.annotation.Resource;
import java.time.Duration;

/**
 * @author
 * @datetime 2023-01-14 11:04:28
 * @description 消费监听，自动ack
 */
@Slf4j
@Component
public class LogStreamConsumerRunner implements ApplicationRunner, DisposableBean {
    @Resource
    private RedisConnectionFactory redisConnectionFactory;
    @Resource
    private ThreadPoolTaskExecutor threadPoolTaskExecutor;
    @Resource
    private LogStreamConsumer logStreamConsumer;
    @Resource
    private RedisUtils redisUtils;
    private StreamMessageListenerContainer<String, ObjectRecord<String, String>> streamMessageListenerContainer;

    @Override
    public void run(ApplicationArguments args) {
        addConsumeGroup(RedisKeyPrefixConst.OPERATE_LOG_STREAM_KEY, RedisKeyPrefixConst.OPERATE_LOG_CONSUME_GROUP);
        addConsumeGroup(RedisKeyPrefixConst.LOGIN_LOG_STREAM_KEY, RedisKeyPrefixConst.LOGIN_LOG_CONSUME_GROUP);

        threadPoolTaskExecutor.setMaxPoolSize(100);

        // 创建配置对象
        StreamMessageListenerContainer.StreamMessageListenerContainerOptions<String, ObjectRecord<String, String>> options =
                StreamMessageListenerContainer.StreamMessageListenerContainerOptions
                        .builder()
                        // 一次性最多拉取多少条消息
                        .batchSize(10)
                        //执行消息轮询的执行器
                        .executor(this.threadPoolTaskExecutor)
                        // 消息消费异常的handler
                        .errorHandler(Throwable::printStackTrace)
                        //超时时间，设置为0，表示不超时（超时后会抛出异常）
                        .pollTimeout(Duration.ZERO)
                        // 序列化器
                        .serializer(new StringRedisSerializer())
                        .targetType(String.class)
                        .build();
        //根据配置对象创建监听容器对象
        streamMessageListenerContainer = StreamMessageListenerContainer.create(this.redisConnectionFactory, options);
        //使用监听容器对象开始监听消费
        receiveAutoAck(RedisKeyPrefixConst.OPERATE_LOG_CONSUME_GROUP, RedisKeyPrefixConst.OPERATE_LOG_CONSUME_NAME, RedisKeyPrefixConst.OPERATE_LOG_STREAM_KEY);
        receiveAutoAck(RedisKeyPrefixConst.LOGIN_LOG_CONSUME_GROUP, RedisKeyPrefixConst.LOGIN_LOG_CONSUME_NAME, RedisKeyPrefixConst.LOGIN_LOG_STREAM_KEY);
        //启动监听
        streamMessageListenerContainer.start();
    }

    private void receiveAutoAck(String consumeGroup, String consumeName, String streamKey) {
        streamMessageListenerContainer.receiveAutoAck(
                Consumer.from(consumeGroup, consumeName),
                StreamOffset.create(streamKey, ReadOffset.lastConsumed()), this.logStreamConsumer);
    }

    private void addConsumeGroup(String streamKey, String consumeGroup) {
        if (redisUtils.hasKey(streamKey)) {
            StreamInfo.XInfoGroups groups = redisUtils.groups(streamKey);
            if (groups.isEmpty()) {
                redisUtils.addGroup(streamKey, consumeGroup);
            }
        } else {
            redisUtils.addGroup(streamKey, consumeGroup);
        }
    }

    @Override
    public void destroy() {
        this.streamMessageListenerContainer.stop();
    }
}

进行消费进行日志增加

package com.hwd.campus.manage.biz.listener;

import cn.hutool.json.JSONUtil;
import com.hwd.campus.manage.biz.model.vo.LoginVo;
import com.hwd.campus.manage.biz.service.ILoginLogService;
import com.hwd.campus.manage.biz.service.IOperateLogService;
import com.hwd.campus.common.redis.constant.RedisKeyPrefixConst;
import com.hwd.campus.common.redis.utils.RedisUtils;
import com.hwd.campus.common.web.filter.model.OperateLogModel;
import lombok.AllArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.springframework.data.redis.connection.stream.ObjectRecord;
import org.springframework.data.redis.stream.StreamListener;
import org.springframework.stereotype.Component;

import java.util.Objects;

/**
 * @author
 */
@Component
@Slf4j
@AllArgsConstructor
public class LogStreamConsumer implements StreamListener<String, ObjectRecord<String, String>> {

    private RedisUtils redisUtils;
    private IOperateLogService manageOperateLogService;
    private ILoginLogService manageLoginLogService;

    @Override
    public void onMessage(ObjectRecord<String, String> message) {
        log.info("接受到来自redis的消息");
        log.info(("message id " + message.getId().getValue()));

        String stream = message.getStream();
        log.info(("stream " + stream));

        Object value = message.getValue();
        log.info(("value " + value));

        if (RedisKeyPrefixConst.OPERATE_LOG_STREAM_KEY.equals(stream)) {
            OperateLogModel operateLogModel = JSONUtil.toBean(message.getValue(), OperateLogModel.class);
            manageOperateLogService.addOperateLog(operateLogModel);
        } else if (RedisKeyPrefixConst.LOGIN_LOG_STREAM_KEY.equals(stream)) {
            LoginVo loginVo = JSONUtil.toBean(message.getValue(), LoginVo.class);
            manageLoginLogService.addLoginLog(loginVo);
        }

        //消费完毕删除该条消息
        redisUtils.streamDelete(Objects.requireNonNull(stream), message.getId().getValue());
    }
}

可通过接口往stream里面set值

redisUtils.addStream(RedisKeyPrefixConst.LOGIN_LOG_STREAM_KEY, JSONUtil.toJsonStr(loginVo));
