在WPF中使用ObservableCollections显示Microsoft.Extensions.Logging的日志信息

背景

先前一段时间用RichTextBox实现了Microsoft.Extension.Logger的日志显示。虽然是用RichTextBox总感觉哪里不对劲，想要添加过滤显得非常复杂。最近了解并学习了ObservableCollection这个库（有点火星救援了啊），遂想到了一个更好的实现方式。

引入ObservableCollections库

1. 在包管理中引入ObservableCollections库

可观察的日志

1. 首先定义一个Log实体LogMessage。为了后面更好实现Filiter功能，添加LogLevel，EventId等属性。
2. 在应用程序运行期间，需要有个存储LogMessage的地方，这里定义接口ILogMessageHolder, 使用ObservableFixedSizeRingBuffer做容器（环形数组，可以使用指定大小的size），整个Observable Logs就是这个ObservableCollections库里的容器。

public struct LogMessage
{
    public LogLevel LogLevel { get; set;}
    public EventId EventId { get; set;}
    public string Category { get; set;}
    public DateTime Time { get; set;}
    public string Message { get; set;}
}

public interface ILoggerMessageHolder
{
    public ObservableFixedSizeRingBuffer<LogMessage> LogMessages {get;}
}

实现Logger等其他东西

1. 实现LogMessageProcessor, 这里依然参照ConsoleLoggerProcessor的实现。（有个疑问，直接往LogMessage容器里添加新项，性能能开销应该不大，这里还需要使用工作线程来执行Enqueue操作吗?）

internal class LogMessageProcessor
{
    //... 省略字段和其余方法实现

    public LogMessageProcessor(ILogMessageHolder logMessageHolder, LoggerQueueFullMode fullMode, int maxQueueLength)
    {
        _logMessageHolder = logMessageHolder;
        _messageQueue = new();
        FullMode = fullMode;
        MaxQueueLength = maxQueueLength;
        _outputThread = new Thread(ProcessMessageQueue)
        {
            IsBackground = true,
            Name = "LogMessage queue processing thread"
        };
        _outputThread.Start();
    }

    //将 WriteMessage 中写入Console的部分修改为往LogMessage容器里添加LogMessage
    internal void WriteMessage(LogMessage message)
    {
        try
        {
            _logMessageHolder.LogMessages.AddLast(message);
        }
        catch
        {
            CompleteAdding();
        }
    }
}

1. 实现Logger。其实这里的LogFormatter属性可要可不要，因为这里的Formatter只对TState做格式化，可以直接做成一个内部的格式化器。当然，这里使用LogFormatter方便后期直接在配置中直接替换实现

internal class Logger : ILogger
{
    private readonly string _category;
    private readonly LogMessageProcessor _processor;
    private StringWriter? t_stringWriter;
    internal IExternalScopeProvider ScopeProvider { get; set; }
    public Logger(string category, LogMessageProcessor processor, LogFormatter formatter,IExternalScopeProvider scopeProvider)
    {
        _category = category;
        _processor = processor;
        Formatter = formatter;
        ScopeProvider = scopeProvider;
    }

    public LogFormatter Formatter { get; set; }

    public IDisposable? BeginScope<TState>(TState state) where TState : notnull
    {
        return ScopeProvider.Push(state) ?? NullScope.Instance;
    }

    public bool IsEnabled(LogLevel logLevel)
    {
        return true;
    }

    public void Log<TState>(LogLevel logLevel, EventId eventId, TState state, Exception? exception, Func<TState, Exception?, string> formatter)
    {
        t_stringWriter ??= new StringWriter();
        var entry = new LogEntry<TState>(logLevel, _category, eventId, state, exception, formatter);

        Formatter.Write(entry, t_stringWriter);

        var sb = t_stringWriter.GetStringBuilder();
        var computedString = sb.ToString();
        sb.Clear();
        _processor.WriteMessage(new LogMessage()
        {
            Time = DateTime.Now,
            Id = eventId,
            Level = logLevel,
            Category = _category,
            Message = computedString,
        });
    }
}

1. 实现LoggerProvider和LoggingBuilderExtension

internal class LoggerProvider : ILoggerProvider
{
    private readonly LogFormatter _formatter;
    private readonly ConcurrentDictionary<string, Logger> _loggers = [];
    private readonly LogMessageProcessor _processor;

    public LoggerProvider(ILogMessageHolder holder, LogFormatter formatter)
    {
        _formatter = formatter;
        _processor = new LogMessageProcessor(holder, LoggerQueueFullMode.Wait, 2500);
    }

    public ILogger CreateLogger(string categoryName)
    {
        return _loggers.GetOrAdd(categoryName, new Logger(categoryName, _processor, _formatter));
    }

    public void Dispose()
    {
        _processor.Dispose();
    }
}

public static class LoggingBuilderExtension
{
    public static ILoggingBuilder AddObservableLogs(this ILoggingBuilder builder)
    {
        builder.Services.AddSingleton<ILoggerProvider, LoggerProvider>();
        builder.Services.AddSingleton<IMfgLoggerProvider, LoggerProvider>();
        builder.Services.AddTransient<LogFormatter, SimpleLogFormatter>();
        builder.Services.AddSingleton<ILogMessageHolder, LogMessageHolder>();
        return builder;
    }
}

• 至此，Logger的核心已经完成，接下来是在View中显示Log

简单实现LogViewer

1. 创建LogWindow,使用ItemsControl显示LogMessage。

   实际上，LogMessage的Formatter，是下文的LogMessageConverter。

public class LogMessageConverter : IValueConverter
{
public object Convert(object value, Type targetType, object parameter, CultureInfo culture)
{
    if (value is not LogMessage message)
    {
        return "";
    }
    return $"{message.Time:yyyy-MM-dd HH:mm:ss,fff} {GetLogLevelString(message.LogLevel)}: {message.Category} [{message.EventId}]\r\n{message.Message}";
}

public object ConvertBack(object value, Type targetType, object parameter, CultureInfo culture)
{
    throw new NotImplementedException();
}

private static string GetLogLevelString(LogLevel logLevel) => logLevel switch
{
    LogLevel.Trace => "trce",
    LogLevel.Debug => "dbug",
    LogLevel.Information => "info",
    LogLevel.Warning => "warn",
    LogLevel.Error => "fail",
    LogLevel.Critical => "crit",
    _ => throw new ArgumentOutOfRangeException(nameof(logLevel))
};
}

<!--省略Window的命名空间和其余属性-->
<ItemsControl ItemsSource="{Binding LogMessages}">
    <ItemsControl.ItemTemplate>
        <DataTemplate>
            <!--如果想要显示日志等级的颜色，需要其他TextBlock和添加trigger-->
            <TextBlock Text="{Binding ., Converter={StaticResource LogMessageConverter}}"></TextBlock>
        </DataTemplate>
    </ItemsControl.ItemTemplate>
</ItemsControl>

1. 创建LogWindow的DataContext

   这里就涉及到ObservableCollections库的知识了，最后绑定到View上的是LogMessages属性。如果想对LogMessages进行过滤，比如选取LogLevel.Information等，使用_viewList的AttachFiliter就好啦。

public class LogWindowViewModel
{
    private readonly ISynchronizedView<LogMessage, LogMessage> _viewList;
    private readonly ILogMessageHolder _logMessageHolder;

    public LogWindowViewModel(ILogMessageHolder logMessageHolder)
    {
        _logMessageHolder = logMessageHolder;
        _viewList = logMessageHolder.LogMessages.CreateView(x => x);
        LogMessages = _viewList.ToNotifyCollectionChanged();
    }

    public INotifyCollectionChangedSynchronizedViewList<LogMessage> LogMessages { get; }
}

结尾

使用ObservableCollections可以非常简单的将LogMessage显示到某个UI上，并且LogMessages的生命周期是跟随应用程序，随时可以打开查看应用程序的日志。由于ObservableCollections是纯C#实现，理论上是可以在Avalonia中使用的。
