一、MGR+Consul架构简介

基于目前存在很多MySQL数据库单点故障，传统的MHA，PXC等方案用VIP或者DNS切换的方式可以实现、基于数据库的数据强一致性考虑，采用MGR集群，采用consul服务注册发现实现应用端通过动态DNS 访问MGR集群，实现数据库高可用，自动化切换的方案。

有关MGR之前发布过几篇文章，连接如下：

【DB宝18】在Docker中安装使用MySQL高可用之MGR

【DB宝35】使用MySQL 8.0 克隆(clone)插件快速添加MGR节点

本次环境一共包括7台机器，其中3台做MySQL的MGR数据节点（其上也需要安装Consul，作为Consul Client），单主模式，还有3台做Consul Server集群，实现Consul的高可用，剩下一台做DNS服务器，用来解析MGR节点域名，规划如下表所示：

二、搭建MGR

2.1、申请3台MGR机器

-- 拉取镜像

docker pull lhrbest/lhrcentos76:8.0

-- 创建专用网络

docker network create --subnet=192.168.68.0/16 mhalhr

docker network inspect mhalhr

-- 生成3台CentOS的环境

docker rm -f mysql8022mgr33060 mysql8022mgr33061 mysql8022mgr33062

docker run -d --name mysql8022mgr33060  -h lhrmgr60  \

--network mhalhr --ip 192.168.68.60 --privileged=true \

-p 33060:3306   \

-v /sys/fs/cgroup:/sys/fs/cgroup \

lhrbest/lhrcentos76:8.0 init

docker run -d --name mysql8022mgr33061  -h lhrmgr61  \

--network mhalhr --ip 192.168.68.61 --privileged=true \

-p 33061:3306   \

-v /sys/fs/cgroup:/sys/fs/cgroup \

lhrbest/lhrcentos76:8.0 init

docker run -d --name mysql8022mgr33062  -h lhrmgr62  \

--network mhalhr --ip 192.168.68.62 --privileged=true \

-p 33062:3306   \

-v /sys/fs/cgroup:/sys/fs/cgroup \

lhrbest/lhrcentos76:8.0 init

-- 拷贝MySQL安装文件到MySQL容器内

docker cp mysql-8.0.22-1.el7.x86_64.rpm-bundle.tar mysql8022mgr33060:/

docker cp mysql-8.0.22-1.el7.x86_64.rpm-bundle.tar mysql8022mgr33061:/

docker cp mysql-8.0.22-1.el7.x86_64.rpm-bundle.tar mysql8022mgr33062:/

docker network connect bridge mysql8022mgr33060

docker network connect bridge mysql8022mgr33061

docker network connect bridge mysql8022mgr33062

docker restart  mysql8022mgr33060 mysql8022mgr33061 mysql8022mgr33062

2.2、3台主机安装MySQL环境

docker exec -it mysql8022mgr33060 bash

docker exec -it mysql8022mgr33061 bash

docker exec -it mysql8022mgr33062 bash

tar -xvf mysql-8.0.22-1.el7.x86_64.rpm-bundle.tar

yum localinstall -y mysql-community-*.rpm

--去掉密码验证策略

mv /usr/lib64/mysql/plugin/validate_password.so /usr/lib64/mysql/plugin/validate_password.so_bk

mv /usr/lib64/mysql/plugin/component_validate_password.so /usr/lib64/mysql/plugin/component_validate_password.so_bk

-- 启动mysql

systemctl start mysqld

systemctl status mysqld

-- 修改密码

grep 'temporary password' /var/log/mysqld.log

mysql -uroot -p

alter user root@'localhost' identified with mysql_native_password by 'lhr';

grant all on *.* to root@'localhost' with grant option;

create user root@'%' identified with mysql_native_password by 'lhr';

grant all on *.* to root@'%' with grant option;

flush privileges;

select user,host,grant_priv,super_priv,authentication_string,password_last_changed from mysql.user;

2.3、修改MySQL参数

-- 节点1

cat > /etc/my.cnf <<"EOF"

[mysqld]

user=mysql

port=3306

character_set_server=utf8mb4

secure_file_priv=

server-id = 802233060

default-time-zone = '+8:00'

log_timestamps = SYSTEM

log-bin =

binlog_format=row

binlog_checksum=NONE

skip-name-resolve

log_slave_updates = 1

gtid-mode=ON

enforce-gtid-consistency=on

default_authentication_plugin=mysql_native_password

max_allowed_packet = 500M

master_info_repository=TABLE

relay_log_info_repository=TABLE

relay_log=lhrmgr60-relay-bin

transaction_write_set_extraction=XXHASH64

loose-group_replication_group_name="aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa"

loose-group_replication_start_on_boot=OFF

loose-group_replication_local_address= "192.168.68.60:33061"

loose-group_replication_group_seeds= "192.168.68.60:33061,192.168.68.61:33061,192.168.68.62:33061"

loose-group_replication_bootstrap_group=OFF

loose-group_replication_ip_whitelist="192.168.68.60,192.168.68.61,192.168.68.62"

report_host=192.168.68.60

report_port=3306

EOF

-- 节点2

cat >  /etc/my.cnf <<"EOF"

[mysqld]

user=mysql

port=3306

character_set_server=utf8mb4

secure_file_priv=

server-id = 802233061

default-time-zone = '+8:00'

log_timestamps = SYSTEM

log-bin =

binlog_format=row

binlog_checksum=NONE

log_slave_updates = 1

gtid-mode=ON

enforce-gtid-consistency=ON

skip_name_resolve

default_authentication_plugin=mysql_native_password

max_allowed_packet = 500M

master_info_repository=TABLE

relay_log_info_repository=TABLE

relay_log=lhrmgr61-relay-bin

transaction_write_set_extraction=XXHASH64

loose-group_replication_group_name="aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa"

loose-group_replication_start_on_boot=OFF

loose-group_replication_local_address= "192.168.68.61:33061"

loose-group_replication_group_seeds= "192.168.68.60:33061,192.168.68.61:33061,192.168.68.62:33061"

loose-group_replication_bootstrap_group=OFF

loose-group_replication_ip_whitelist="192.168.68.60,192.168.68.61,192.168.68.62"

report_host=192.168.68.61

report_port=3306

EOF

-- 节点3

cat > /etc/my.cnf <<"EOF"

[mysqld]

user=mysql

port=3306

character_set_server=utf8mb4

secure_file_priv=

server-id = 802233062

default-time-zone = '+8:00'

log_timestamps = SYSTEM

log-bin =

binlog_format=row

binlog_checksum=NONE

log_slave_updates = 1

gtid-mode=ON

enforce-gtid-consistency=ON

skip_name_resolve

default_authentication_plugin=mysql_native_password

max_allowed_packet = 500M

master_info_repository=TABLE

relay_log_info_repository=TABLE

relay_log=lhrmgr62-relay-bin

transaction_write_set_extraction=XXHASH64

loose-group_replication_group_name="aaaaaaaa-aaaa-aaaa-aaaa-aaaaaaaaaaaa"

loose-group_replication_start_on_boot=OFF

loose-group_replication_local_address= "192.168.68.62:33061"

loose-group_replication_group_seeds= "192.168.68.60:33061,192.168.68.61:33061,192.168.68.62:33061"

loose-group_replication_bootstrap_group=OFF

loose-group_replication_ip_whitelist="192.168.68.60,192.168.68.61,192.168.68.62"

report_host=192.168.68.62

report_port=3306

EOF

2.4、重启MySQL环境

-- 重启MySQL

systemctl restart mysqld

-- 进入MySQL

docker exec -it mysql8022mgr33060 bash

docker exec -it mysql8022mgr33060 mysql -uroot -plhr

-- 远程连接MySQL

mysql -uroot -plhr -h192.168.66.35 -P33060

mysql -uroot -plhr -h192.168.66.35 -P33061

mysql -uroot -plhr -h192.168.66.35 -P33062

-- 查看MySQL日志

docker logs -f --tail 10 mysql8022mgr33060

docker logs -f --tail 10 mysql8022mgr33061

docker logs -f --tail 10 mysql8022mgr33062

-- 查看MySQL的主机名、server_id和server_uuid

mysql -uroot -plhr -h192.168.66.35 -P33060 -e "select @@hostname,@@server_id,@@server_uuid"

mysql -uroot -plhr -h192.168.66.35 -P33061 -e "select @@hostname,@@server_id,@@server_uuid"

mysql -uroot -plhr -h192.168.66.35 -P33062 -e "select @@hostname,@@server_id,@@server_uuid"

结果：

C:\Users\lhrxxt>mysql -uroot -plhr -h192.168.66.35 -P33060 -e "select @@hostname,@@server_id,@@server_uuid"

mysql: [Warning] Using a password on the command line interface can be insecure.

+------------+-------------+--------------------------------------+

| @@hostname | @@server_id | @@server_uuid                        |

+------------+-------------+--------------------------------------+

| lhrmgr60   |   802233060 | 44c693d8-80bb-11eb-b4bb-0242c0a8443c |

+------------+-------------+--------------------------------------+

C:\Users\lhrxxt>mysql -uroot -plhr -h192.168.66.35 -P33061 -e "select @@hostname,@@server_id,@@server_uuid"

mysql: [Warning] Using a password on the command line interface can be insecure.

+------------+-------------+--------------------------------------+

| @@hostname | @@server_id | @@server_uuid                        |

+------------+-------------+--------------------------------------+

| lhrmgr61   |   802233061 | 408acdb5-80bc-11eb-97a7-0242c0a8443d |

+------------+-------------+--------------------------------------+

C:\Users\lhrxxt>mysql -uroot -plhr -h192.168.66.35 -P33062 -e "select @@hostname,@@server_id,@@server_uuid"

mysql: [Warning] Using a password on the command line interface can be insecure.

+------------+-------------+--------------------------------------+

| @@hostname | @@server_id | @@server_uuid                        |

+------------+-------------+--------------------------------------+

| lhrmgr62   |   802233062 | 9d5c3e3e-80bc-11eb-a0b2-0242c0a8443e |

+------------+-------------+--------------------------------------+

2.5、安装MGR插件（所有节点执行）

mysql -uroot -plhr -h192.168.66.35 -P33060

INSTALL PLUGIN group_replication SONAME 'group_replication.so';

-- 如果MySQL版本大于8.0.17，那么建议再安装clone插件

INSTALL PLUGIN clone SONAME 'mysql_clone.so';

show plugins;

2.6、设置复制账号

-- 在主库(192.168.68.60)上执行

CREATE USER repl@'%' IDENTIFIED BY 'lhr';

GRANT REPLICATION SLAVE,BACKUP_ADMIN ON *.* TO repl@'%';

FLUSH PRIVILEGES;

-- 所有节点执行

CHANGE MASTER TO MASTER_USER='repl', MASTER_PASSWORD='lhr' FOR CHANNEL 'group_replication_recovery';

2.7、启动MGR，在主库(192.168.68.60)上执行

SET GLOBAL group_replication_bootstrap_group=ON;

START GROUP_REPLICATION;

SET GLOBAL group_replication_bootstrap_group=OFF;

-- 查看MGR组信息

SELECT * FROM performance_schema.replication_group_members;

2.8、其他节点加入MGR，在从库（192.168.68.61，192.168.68.62）上执行

reset master;

START GROUP_REPLICATION;

-- 查看MGR组信息

SELECT * FROM performance_schema.replication_group_members;

执行结果：

MySQL [(none)]> SELECT * FROM performance_schema.replication_group_members;

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

| CHANNEL_NAME              | MEMBER_ID                            | MEMBER_HOST   | MEMBER_PORT | MEMBER_STATE | MEMBER_ROLE | MEMBER_VERSION |

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

| group_replication_applier | 408acdb5-80bc-11eb-97a7-0242c0a8443d | 192.168.68.61 |        3306 | ONLINE       | SECONDARY   | 8.0.22         |

| group_replication_applier | 44c693d8-80bb-11eb-b4bb-0242c0a8443c | 192.168.68.60 |        3306 | ONLINE       | PRIMARY     | 8.0.22         |

| group_replication_applier | 9d5c3e3e-80bc-11eb-a0b2-0242c0a8443e | 192.168.68.62 |        3306 | ONLINE       | SECONDARY   | 8.0.22         |

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

3 rows in set (0.05 sec)

可以看到，3个节点状态为online，并且主节点为192.168.68.60，只有主节点可以写入，其他节点只读，MGR单主模式搭建成功。

2.9、测试同步

在主节点上执行以下命令，然后在其它节点查询：

create database lhrdb;

CREATE TABLE lhrdb.`tb1` (

 `id` int(11) NOT NULL AUTO_INCREMENT,

 `hostname` varchar(100) DEFAULT NULL,

 `server_id` varchar(100) DEFAULT NULL,

 PRIMARY KEY (`id`)

) ENGINE=InnoDB DEFAULT CHARSET=latin1;

insert into lhrdb.tb1(hostname,server_id) select @@hostname,@@server_id;

select * from lhrdb.tb1;

-- 3个节点查询出来的值一样

MySQL [(none)]> select * from lhrdb.tb1;

+----+----------+-----------+

| id | hostname | server_id |

+----+----------+-----------+

|  1 | lhrmgr60 | 802233060 |

+----+----------+-----------+

1 row in set (0.05 sec)

三、搭建Consul Server集群

3.1、申请3台Consul Server主机

docker rm -f lhrconsulmgr66  lhrconsulmgr67  lhrconsulmgr68

docker run -d --name lhrconsulmgr66 -h lhrconsulmgr66 \

  --net=mhalhr --ip 192.168.68.66 \

  -p 8566:8500 \

  -v /sys/fs/cgroup:/sys/fs/cgroup \

  --privileged=true lhrbest/lhrcentos76:8.0 \

  /usr/sbin/init

docker run -d --name lhrconsulmgr67 -h lhrconsulmgr67 \

  --net=mhalhr --ip 192.168.68.67 \

  -p 8567:8500 \

  --privileged=true lhrbest/lhrcentos76:8.0 \

  /usr/sbin/init

docker run -d --name lhrconsulmgr68 -h lhrconsulmgr68 \

  --net=mhalhr --ip 192.168.68.68 \

  -p 8568:8500 \

  --privileged=true lhrbest/lhrcentos76:8.0 \

  /usr/sbin/init

docker cp consul_1.9.4_linux_amd64.zip lhrconsulmgr66:/

docker cp consul_1.9.4_linux_amd64.zip lhrconsulmgr67:/

docker cp consul_1.9.4_linux_amd64.zip lhrconsulmgr68:/

docker network connect bridge lhrconsulmgr66

docker network connect bridge lhrconsulmgr67

docker network connect bridge lhrconsulmgr68

docker restart  lhrconsulmgr66 lhrconsulmgr67 lhrconsulmgr68

3.2、安装Consul Server

docker exec -it lhrconsulmgr66 bash

docker exec -it lhrconsulmgr67 bash

docker exec -it lhrconsulmgr68 bash

unzip consul_1.9.4_linux_amd64.zip

mv consul /usr/local/bin/

mkdir -p /consul/logs/

-- 66节点	启动

nohup consul agent -server -bootstrap-expect 3 -bind=192.168.68.66 -client=0.0.0.0 -data-dir=/consul/data \

-node=n66 -ui >> /consul/logs/consul.log 2>&1 &

-- 67节点	启动

nohup consul agent -server -bootstrap-expect 3 -bind=192.168.68.67 -client=0.0.0.0 -data-dir=/consul/data \

-node=n67 -ui >> /consul/logs/consul.log 2>&1 &

-- 68节点	启动

nohup consul agent -server -bootstrap-expect 3 -bind=192.168.68.68 -client=0.0.0.0 -data-dir=/consul/data \

-node=n68 -ui >> /consul/logs/consul.log 2>&1 &

-- 67和68节点加入集群

consul join 192.168.68.66

-- 查询集群状态

[root@lhrconsulmgr66 /]# consul members

Node  Address             Status  Type    Build  Protocol  DC   Segment

n66   192.168.68.66:8301  alive   server  1.9.4  2         dc1  <all>

n67   192.168.68.67:8301  alive   server  1.9.4  2         dc1  <all>

n68   192.168.68.68:8301  alive   server  1.9.4  2         dc1  <all>

[root@lhrconsulmgr66 /]# consul operator raft list-peers

Node  ID                                    Address             State     Voter  RaftProtocol

n66   719e2a32-5c4b-bd0f-35ef-9ac11a8e79e0  192.168.68.66:8300  leader    true   3

n67   f80e2542-3d30-ca5a-af79-08879723c882  192.168.68.67:8300  follower  true   3

n68   43520b16-1b65-7d22-4172-6c2822070a44  192.168.68.68:8300  follower  true   3

为了后续启动方便，我们使用参数文件：

-- 66节点，其它节点修改node_name、advertise_addr和bind_addr即可：

mkdir -p /etc/consul.d/

pkill -9 consul

cat > /etc/consul.d/server.json  <<"EOF"

{

  "data_dir": "/consul/data",

  "datacenter": "dc1",

  "node_name": "n66",

  "enable_syslog": true,

  "log_level": "INFO",

  "server": true,

  "advertise_addr":"192.168.68.66",

  "bootstrap_expect": 3,

  "bind_addr": "192.168.68.66",

  "client_addr": "0.0.0.0",

  "retry_join": ["192.168.68.66","192.168.68.67","192.168.68.68"],

  "retry_interval": "10s",

  "rejoin_after_leave": true,

  "start_join": ["192.168.68.66","192.168.68.67","192.168.68.68"] ,

  "ui": true

}

EOF

nohup consul agent -config-dir=/etc/consul.d > /consul/consul.log &

3.3、web访问

http://192.168.66.35:8566

http://192.168.66.35:8567

http://192.168.66.35:8568

四、在MySQL节点上安装Consul Client

4.1、安装Consul Client

docker cp consul_1.9.4_linux_amd64.zip mysql8022mgr33060:/

docker cp consul_1.9.4_linux_amd64.zip mysql8022mgr33061:/

docker cp consul_1.9.4_linux_amd64.zip mysql8022mgr33062:/

docker exec -it mysql8022mgr33060 bash

unzip consul_1.9.4_linux_amd64.zip

mv consul /usr/local/bin/

mkdir -p /consul/logs/

-- mgr60配置文件，其它节点修改bind_addr和node_name即可

mkdir -p /etc/consul.d/

cat > /etc/consul.d/client.json <<"EOF"

{

  "data_dir": "/data/consul",

  "enable_script_checks": true,

  "bind_addr": "192.168.68.60",

  "retry_join": ["192.168.68.66","192.168.68.67","192.168.68.68"],

  "retry_interval": "10s",

  "rejoin_after_leave": true,

  "start_join": ["192.168.68.66","192.168.68.67","192.168.68.68"] ,

  "node_name": "MGR60"

}

EOF

nohup consul agent -config-dir=/etc/consul.d > /consul/consul.log &

查询状态：



[root@lhrconsulmgr66 /]# consul members

Node   Address             Status  Type    Build  Protocol  DC   Segment

n66    192.168.68.66:8301  alive   server  1.9.4  2         dc1  <all>

n67    192.168.68.67:8301  alive   server  1.9.4  2         dc1  <all>

n68    192.168.68.68:8301  alive   server  1.9.4  2         dc1  <all>

MGR60  192.168.68.60:8301  alive   client  1.9.4  2         dc1  <default>

MGR61  192.168.68.61:8301  alive   client  1.9.4  2         dc1  <default>

MGR62  192.168.68.62:8301  alive   client  1.9.4  2         dc1  <default>

[root@lhrconsulmgr66 /]#  consul operator raft list-peers

Node  ID                                    Address             State     Voter  RaftProtocol

n66   719e2a32-5c4b-bd0f-35ef-9ac11a8e79e0  192.168.68.66:8300  follower  true   3

n67   f80e2542-3d30-ca5a-af79-08879723c882  192.168.68.67:8300  leader    true   3

n68   43520b16-1b65-7d22-4172-6c2822070a44  192.168.68.68:8300  follower  true   3

4.2、在Consul client的3个节点上编写检测primay脚本和检测slave脚本

-- 检测脚本【master】

mkdir -p /data/consul/shell/

cat > /data/consul/shell/check_mysql_mgr_master.sh  <<"EOF"

#!/bin/bash

port=3306

user="root"

passwod="lhr"

comm="/usr/bin/mysql -u$user -hlocalhost -P $port -p$passwod"

value=`$comm -Nse "select 1"`

primary_member=`$comm -Nse "select variable_value from performance_schema.global_status WHERE VARIABLE_NAME= 'group_replication_primary_member'"`

server_uuid=`$comm -Nse "select variable_value from performance_schema.global_variables where VARIABLE_NAME='server_uuid';"`

# 判断MySQL是否存活

if [ -z $value ]

then

   echo "mysql $port is down....."

   exit 2

fi

# 判断节点状态,是否存活

node_state=`$comm -Nse "select MEMBER_STATE from performance_schema.replication_group_members where MEMBER_ID='$server_uuid'"`

if [ $node_state != "ONLINE" ]

then

   echo "MySQL $port state is not online...."

   exit 2

fi

# 判断是不是主节点

if [[ $server_uuid == $primary_member ]]

then

   echo "MySQL $port Instance is master ........"

   exit 0

else

   echo "MySQL $port Instance is slave ........"

   exit 2

fi

EOF

-- 检测脚本【slave】

cat > /data/consul/shell/check_mysql_mgr_slave.sh <<"EOF"

#!/bin/bash

port=3306

user="root"

passwod="lhr"

comm="/usr/bin/mysql -u$user -hlocalhost -P $port -p$passwod"

value=`$comm -Nse "select 1"`

primary_member=`$comm -Nse "select variable_value from performance_schema.global_status WHERE VARIABLE_NAME= 'group_replication_primary_member'"`

server_uuid=`$comm -Nse "select variable_value from performance_schema.global_variables where VARIABLE_NAME='server_uuid';"`

# 判断mysql是否存活

if [ -z $value ]

then

   echo "mysql $port is down....."

   exit 2

fi

# 判断节点状态

node_state=`$comm -Nse "select MEMBER_STATE from performance_schema.replication_group_members where MEMBER_ID='$server_uuid'"`

if [ $node_state != "ONLINE" ]

then

   echo "MySQL $port state is not online...."

   exit 2

fi

# 判断是不是主节点

if [[ $server_uuid != $primary_member ]]

then

   echo "MySQL $port Instance is slave ........"

   exit 0

else

   node_num=`$comm -Nse "select count(*) from performance_schema.replication_group_members"`

# 判断如果没有任何从节点，主节点也注册从角色服务。

   if [ $node_num -eq 1 ]

   then

       echo "MySQL $port Instance is slave ........"

       exit 0

   else

       echo "MySQL $port Instance is master ........"

       exit 2

   fi

fi

EOF

赋权：

chmod +x /data/consul/shell/check_mysql_mgr_master.sh

chmod +x /data/consul/shell/check_mysql_mgr_slave.sh

4.3、service配置

官网配置参考：https://www.consul.io/docs/discovery/services

在3台MySQL节点上都需要操作，注意修改address地址为本机地址：

cat > /etc/consul.d/rw-mysql-mgr-server-lhr.json <<"EOF"

{

  "service":

    {

      "name": "rw-mysql-mgr-server-lhr",

      "tags": ["MGR-Master"],

      "address": "192.168.68.60",

      "port": 3306,

      "check":

        {

          "args": ["/data/consul/shell/check_mysql_mgr_master.sh"],

          "interval": "5s"

        }

    }

}

EOF

cat > /etc/consul.d/r-mysql-mgr-server-lhr.json <<"EOF"

{

  "service": [

    {

      "name": "r-mysql-mgr-server-lhr",

      "tags": ["MGR-Slave"],

      "address": "192.168.68.60",

      "port": 3306,

      "check":

        {

          "args": ["/data/consul/shell/check_mysql_mgr_slave.sh"],

          "interval": "5s"

        }

    }

  ]

}

EOF

-- 检查配置文件是否正常

consul validate /etc/consul.d/

-- 重新加载配置文件

consul reload

-- 检查配置结果

[root@lhrmgr60 ~]# consul catalog services

consul

r-mysql-mgr-server-lhr

rw-mysql-mgr-server-lhr

注意：由于每台mysql server 上都有master、slave 检测脚本、而mysql server 只能是master 或者slave、所以存在失败的检测，master检测只有一个成功，slave检测只有一个失败。

所有服务：

主库连接：

从库连接：

4.4、service测试

yum install -y bind-utils bind bind-chroot dnsmasq

dig @192.168.68.66  -p 8600 r-mysql-mgr-server-lhr.service.consul a

dig @192.168.68.66  -p 8600 rw-mysql-mgr-server-lhr.service.consul a

dig @127.0.0.1 -p 8600 MGR60.node.consul

dig @127.0.0.1 -p 8600 MGR61.node.consul

dig @127.0.0.1 -p 8600 MGR62.node.consul

测试结果：

[root@lhrmgr60 ~]# dig @192.168.68.66  -p 8600 r-mysql-mgr-server-lhr.service.consul a

; <<>> DiG 9.11.4-P2-RedHat-9.11.4-26.P2.el7_9.4 <<>> @192.168.68.66 -p 8600 r-mysql-mgr-server-lhr.service.consul a

; (1 server found)

;; global options: +cmd

;; Got answer:

;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 7862

;; flags: qr aa rd; QUERY: 1, ANSWER: 2, AUTHORITY: 0, ADDITIONAL: 1

;; WARNING: recursion requested but not available

;; OPT PSEUDOSECTION:

; EDNS: version: 0, flags:; udp: 4096

;; QUESTION SECTION:

;r-mysql-mgr-server-lhr.service.consul. IN A

;; ANSWER SECTION:

r-mysql-mgr-server-lhr.service.consul. 0 IN A   192.168.68.62

r-mysql-mgr-server-lhr.service.consul. 0 IN A   192.168.68.61

;; Query time: 0 msec

;; SERVER: 192.168.68.66#8600(192.168.68.66)

;; WHEN: Wed Mar 10 10:52:12 CST 2021

;; MSG SIZE  rcvd: 98

[root@lhrmgr60 ~]# dig @192.168.68.66  -p 8600 rw-mysql-mgr-server-lhr.service.consul A

; <<>> DiG 9.11.4-P2-RedHat-9.11.4-26.P2.el7_9.4 <<>> @192.168.68.66 -p 8600 rw-mysql-mgr-server-lhr.service.consul a

; (1 server found)

;; global options: +cmd

;; Got answer:

;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 13129

;; flags: qr aa rd; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 1

;; WARNING: recursion requested but not available

;; OPT PSEUDOSECTION:

; EDNS: version: 0, flags:; udp: 4096

;; QUESTION SECTION:

;rw-mysql-mgr-server-lhr.service.consul.        IN A

;; ANSWER SECTION:

rw-mysql-mgr-server-lhr.service.consul. 0 IN A  192.168.68.60

;; Query time: 0 msec

;; SERVER: 192.168.68.66#8600(192.168.68.66)

;; WHEN: Wed Mar 10 10:52:17 CST 2021

;; MSG SIZE  rcvd: 83

可以看到，r-mysql-mgr-server-lhr.service.consul解析出来的地址是192.168.68.61和192.168.68.62，即2个从库；而rw-mysql-mgr-server-lhr.service.consul解析出来的地址为192.168.68.60，即主库。

五、配置DNS解析域名

App端配置域名服务器来解析consul后缀的域名，DNS解析及跳转，有多个方案：

原内网dns服务器,做域名转发，consul后缀的，都转到consul server上

dns全部跳到consul DNS服务器上，非consul后缀的,使用 recursors 属性跳转到原DNS服务器上

dnsmaq 转： server=/consul/192.168.X.X#8600 解析consul后缀的

使用BIND配置DNS服务器

这里只列举dnsmasq这种方案，更多方法请参考官方文档：https://learn.hashicorp.com/tutorials/consul/dns-forwarding

5.1、使用dnsmasq来配置DNS解析

在192.168.66.69上配置dnsmasq。

docker rm -f lhrconsuldns69

docker run -d --name lhrconsuldns69 -h lhrconsuldns69 \

  --net=mhalhr --ip 192.168.68.69 \

  -p 53:53 \

  -v /sys/fs/cgroup:/sys/fs/cgroup \

  --privileged=true lhrbest/lhrcentos76:8.0 \

  /usr/sbin/init

docker network connect bridge lhrconsuldns69

docker exec -it lhrconsuldns69 bash

yum install -y bind-utils bind bind-chroot dnsmasq

echo "

server=/consul/192.168.68.66#8600

server=/consul/192.168.68.67#8600

server=/consul/192.168.68.68#8600

" > /etc/dnsmasq.d/10-consul

echo "

server=114.114.114.114

server=8.8.8.8

server=223.5.5.5

" >> /etc/dnsmasq.conf

-- 添加到所有机器，包括本机、3个client、3个server端等

echo "nameserver 192.168.68.69" > /etc/resolv.conf

systemctl enable dnsmasq

systemctl restart dnsmasq

systemctl status dnsmasq

dig @192.168.68.69  -p 53 r-mysql-mgr-server-lhr.service.consul a

dig @192.168.68.69  -p 53 rw-mysql-mgr-server-lhr.service.consul a

nslookup r-mysql-mgr-server-lhr.service.consul

nslookup rw-mysql-mgr-server-lhr.service.consul

ping r-mysql-mgr-server-lhr.service.consul -c 4

ping rw-mysql-mgr-server-lhr.service.consul -c 4

结果：

[root@lhrmgr60 /]# nslookup r-mysql-mgr-server-lhr.service.consul

nslookup rw-mysql-mgr-server-lhr.service.consulServer:          192.168.68.69

Address:        192.168.68.69#53

Name:   r-mysql-mgr-server-lhr.service.consul

Address: 192.168.68.62

Name:   r-mysql-mgr-server-lhr.service.consul

Address: 192.168.68.61

[root@lhrmgr60 /]# nslookup rw-mysql-mgr-server-lhr.service.consul

Server:         192.168.68.69

Address:        192.168.68.69#53

Name:   rw-mysql-mgr-server-lhr.service.consul

Address: 192.168.68.60

[root@lhrmgr60 /]#

[root@lhrmgr60 /]# ping r-mysql-mgr-server-lhr.service.consul -c 4

PING r-mysql-mgr-server-lhr.service.consul (192.168.68.61) 56(84) bytes of data.

64 bytes from 192.168.68.61 (192.168.68.61): icmp_seq=1 ttl=64 time=0.083 ms

64 bytes from 192.168.68.61 (192.168.68.61): icmp_seq=2 ttl=64 time=0.065 ms

64 bytes from 192.168.68.61 (192.168.68.61): icmp_seq=3 ttl=64 time=0.108 ms

64 bytes from 192.168.68.61 (192.168.68.61): icmp_seq=4 ttl=64 time=0.084 ms

--- r-mysql-mgr-server-lhr.service.consul ping statistics ---

4 packets transmitted, 4 received, 0% packet loss, time 7022ms

rtt min/avg/max/mdev = 0.065/0.085/0.108/0.015 ms

[root@lhrmgr60 /]#

[root@lhrmgr60 /]# ping rw-mysql-mgr-server-lhr.service.consul -c 4

PING rw-mysql-mgr-server-lhr.service.consul (192.168.68.60) 56(84) bytes of data.

64 bytes from lhrmgr60 (192.168.68.60): icmp_seq=1 ttl=64 time=0.058 ms

64 bytes from lhrmgr60 (192.168.68.60): icmp_seq=2 ttl=64 time=0.070 ms

64 bytes from lhrmgr60 (192.168.68.60): icmp_seq=3 ttl=64 time=0.091 ms

64 bytes from lhrmgr60 (192.168.68.60): icmp_seq=4 ttl=64 time=0.071 ms

--- rw-mysql-mgr-server-lhr.service.consul ping statistics ---

4 packets transmitted, 4 received, 0% packet loss, time 2999ms

rtt min/avg/max/mdev = 0.058/0.072/0.091/0.014 ms

[root@lhrmgr60 /]#

[root@lhrmgr60 /]# dig @192.168.68.69  -p 53 r-mysql-mgr-server-lhr.service.consul a

; <<>> DiG 9.11.4-P2-RedHat-9.11.4-26.P2.el7_9.4 <<>> @192.168.68.69 -p 53 r-mysql-mgr-server-lhr.service.consul a

; (1 server found)

;; global options: +cmd

;; Got answer:

;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 48770

;; flags: qr aa rd ra; QUERY: 1, ANSWER: 2, AUTHORITY: 0, ADDITIONAL: 1

;; OPT PSEUDOSECTION:

; EDNS: version: 0, flags:; udp: 4096

;; QUESTION SECTION:

;r-mysql-mgr-server-lhr.service.consul. IN A

;; ANSWER SECTION:

r-mysql-mgr-server-lhr.service.consul. 0 IN A   192.168.68.62

r-mysql-mgr-server-lhr.service.consul. 0 IN A   192.168.68.61

;; Query time: 1 msec

;; SERVER: 192.168.68.69#53(192.168.68.69)

;; WHEN: Thu Mar 11 10:30:03 CST 2021

;; MSG SIZE  rcvd: 98

[root@lhrmgr60 /]#

[root@lhrmgr60 /]# dig @192.168.68.69  -p 53 rw-mysql-mgr-server-lhr.service.consul a

; <<>> DiG 9.11.4-P2-RedHat-9.11.4-26.P2.el7_9.4 <<>> @192.168.68.69 -p 53 rw-mysql-mgr-server-lhr.service.consul a

; (1 server found)

;; global options: +cmd

;; Got answer:

;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 47378

;; flags: qr aa rd ra; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 1

;; OPT PSEUDOSECTION:

; EDNS: version: 0, flags:; udp: 4096

;; QUESTION SECTION:

;rw-mysql-mgr-server-lhr.service.consul.        IN A

;; ANSWER SECTION:

rw-mysql-mgr-server-lhr.service.consul. 0 IN A  192.168.68.60

;; Query time: 1 msec

;; SERVER: 192.168.68.69#53(192.168.68.69)

;; WHEN: Thu Mar 11 10:30:13 CST 2021

;; MSG SIZE  rcvd: 83

5.2、MySQL通过域名连接

[root@lhrmgr60 /]# mysql -uroot -plhr -hrw-mysql-mgr-server-lhr.service.consul

mysql: [Warning] Using a password on the command line interface can be insecure.

Welcome to the MySQL monitor.  Commands end with ; or \g.

Your MySQL connection id is 53753

Server version: 8.0.22 MySQL Community Server - GPL

Copyright (c) 2000, 2020, Oracle and/or its affiliates. All rights reserved.

Oracle is a registered trademark of Oracle Corporation and/or its

affiliates. Other names may be trademarks of their respective

owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql> SELECT * FROM performance_schema.replication_group_members;

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

| CHANNEL_NAME              | MEMBER_ID                            | MEMBER_HOST   | MEMBER_PORT | MEMBER_STATE | MEMBER_ROLE | MEMBER_VERSION |

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

| group_replication_applier | 408acdb5-80bc-11eb-97a7-0242c0a8443d | 192.168.68.61 |        3306 | ONLINE       | SECONDARY   | 8.0.22         |

| group_replication_applier | 44c693d8-80bb-11eb-b4bb-0242c0a8443c | 192.168.68.60 |        3306 | ONLINE       | PRIMARY     | 8.0.22         |

| group_replication_applier | 9d5c3e3e-80bc-11eb-a0b2-0242c0a8443e | 192.168.68.62 |        3306 | ONLINE       | SECONDARY   | 8.0.22         |

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

3 rows in set (0.00 sec)

mysql> select @@hostname,@@report_host;

+------------+---------------+

| @@hostname | @@report_host |

+------------+---------------+

| lhrmgr60   | 192.168.68.60 |

+------------+---------------+

1 row in set (0.00 sec)

mysql> exit

Bye

[root@lhrmgr60 /]# mysql -uroot -plhr -hr-mysql-mgr-server-lhr.service.consul

mysql: [Warning] Using a password on the command line interface can be insecure.

Welcome to the MySQL monitor.  Commands end with ; or \g.

Your MySQL connection id is 47616

Server version: 8.0.22 MySQL Community Server - GPL

Copyright (c) 2000, 2020, Oracle and/or its affiliates. All rights reserved.

Oracle is a registered trademark of Oracle Corporation and/or its

affiliates. Other names may be trademarks of their respective

owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql> SELECT * FROM performance_schema.replication_group_members;

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

| CHANNEL_NAME              | MEMBER_ID                            | MEMBER_HOST   | MEMBER_PORT | MEMBER_STATE | MEMBER_ROLE | MEMBER_VERSION |

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

| group_replication_applier | 408acdb5-80bc-11eb-97a7-0242c0a8443d | 192.168.68.61 |        3306 | ONLINE       | SECONDARY   | 8.0.22         |

| group_replication_applier | 44c693d8-80bb-11eb-b4bb-0242c0a8443c | 192.168.68.60 |        3306 | ONLINE       | PRIMARY     | 8.0.22         |

| group_replication_applier | 9d5c3e3e-80bc-11eb-a0b2-0242c0a8443e | 192.168.68.62 |        3306 | ONLINE       | SECONDARY   | 8.0.22         |

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

3 rows in set (0.00 sec)

mysql> create database  lhrdb2;

ERROR 1290 (HY000): The MySQL server is running with the --super-read-only option so it cannot execute this statement

六、测试高可用

6.1、测试Consul Server的高可用

如下图所示，目前Consul Server有3台机器，组成一个集群，若其中任意一台机器宕机，都不能影响service的解析：

目前的状态：

[root@lhrmgr60 /]# consul members

Node   Address             Status  Type    Build  Protocol  DC   Segment

n66    192.168.68.66:8301  alive   server  1.9.4  2         dc1  <all>

n67    192.168.68.67:8301  alive   server  1.9.4  2         dc1  <all>

n68    192.168.68.68:8301  alive   server  1.9.4  2         dc1  <all>

MGR60  192.168.68.60:8301  alive   client  1.9.4  2         dc1  <default>

MGR61  192.168.68.61:8301  alive   client  1.9.4  2         dc1  <default>

MGR62  192.168.68.62:8301  alive   client  1.9.4  2         dc1  <default>

[root@lhrmgr60 /]# consul operator raft list-peers

Node  ID                                    Address             State     Voter  RaftProtocol

n68   43520b16-1b65-7d22-4172-6c2822070a44  192.168.68.68:8300  follower  true   3

n66   ca78760f-2f7e-f350-4e47-2db17e8719fe  192.168.68.66:8300  leader    true   3

n67   f80e2542-3d30-ca5a-af79-08879723c882  192.168.68.67:8300  follower  true   3

接下来，把n66、n67进行关机操作：

docker stop  lhrconsulmgr66 lhrconsulmgr67

查询集群状态：

[root@lhrmgr60 /]# consul members

Node   Address             Status  Type    Build  Protocol  DC   Segment

n66    192.168.68.66:8301  failed  server  1.9.4  2         dc1  <all>

n67    192.168.68.67:8301  failed  server  1.9.4  2         dc1  <all>

n68    192.168.68.68:8301  alive   server  1.9.4  2         dc1  <all>

MGR60  192.168.68.60:8301  alive   client  1.9.4  2         dc1  <default>

MGR61  192.168.68.61:8301  alive   client  1.9.4  2         dc1  <default>

MGR62  192.168.68.62:8301  alive   client  1.9.4  2         dc1  <default>

[root@lhrmgr60 /]# consul operator raft list-peers

Error getting peers: Failed to retrieve raft configuration: Unexpected response code: 500 (rpc error making call: No cluster leader)

[root@lhrmgr60 /]# consul catalog services

Error listing services: Unexpected response code: 500 (rpc error making call: No cluster leader)

查询域名是否正常使用：

dig @192.168.68.69  -p 53 r-mysql-mgr-server-lhr.service.consul a

dig @192.168.68.69  -p 53 rw-mysql-mgr-server-lhr.service.consul a

nslookup r-mysql-mgr-server-lhr.service.consul

nslookup rw-mysql-mgr-server-lhr.service.consul

ping r-mysql-mgr-server-lhr.service.consul -c 4

ping rw-mysql-mgr-server-lhr.service.consul -c 4

校验结果：

[root@lhrmgr60 /]# nslookup r-mysql-mgr-server-lhr.service.consul

Server:         192.168.68.69

Address:        192.168.68.69#53

Name:   r-mysql-mgr-server-lhr.service.consul

Address: 192.168.68.61

Name:   r-mysql-mgr-server-lhr.service.consul

Address: 192.168.68.62

[root@lhrmgr60 /]#

[root@lhrmgr60 /]# nslookup rw-mysql-mgr-server-lhr.service.consul

Server:         192.168.68.69

Address:        192.168.68.69#53

Name:   rw-mysql-mgr-server-lhr.service.consul

Address: 192.168.68.60

可以看到，Consul Server集群的高可用运行正常。

6.2、测试MySQL的负载均衡和读写分离

首先测试读负载均衡：

[root@lhrmgr60 /]# for i in $(seq 1 10); do mysql -uroot -plhr -hr-mysql-mgr-server-lhr.service.consul -P3306 \

> -e 'select @@server_id;'; done | egrep '[0-9]'

mysql: [Warning] Using a password on the command line interface can be insecure.

802233061

mysql: [Warning] Using a password on the command line interface can be insecure.

802233061

mysql: [Warning] Using a password on the command line interface can be insecure.

802233062

mysql: [Warning] Using a password on the command line interface can be insecure.

802233062

mysql: [Warning] Using a password on the command line interface can be insecure.

802233062

mysql: [Warning] Using a password on the command line interface can be insecure.

802233061

mysql: [Warning] Using a password on the command line interface can be insecure.

802233061

mysql: [Warning] Using a password on the command line interface can be insecure.

802233061

mysql: [Warning] Using a password on the command line interface can be insecure.

802233062

mysql: [Warning] Using a password on the command line interface can be insecure.

802233061

可以看到，读操作被分配到61和62主机上。

读写分离由于是通过不同的主机域名进行连接的，之前已经测试过，所以，这里就不再测试。

6.3、测试MGR高可用

目前192.168.68.60为主库，192.168.68.61和192.168.68.62为从库，所以，我们把192.168.68.60关机，然后通过域名来连接，检查能否正常连接。

[root@lhrmgr60 /]# mysql -uroot -plhr -hrw-mysql-mgr-server-lhr.service.consul -P3306

mysql: [Warning] Using a password on the command line interface can be insecure.

Welcome to the MySQL monitor.  Commands end with ; or \g.

Your MySQL connection id is 54447

Server version: 8.0.22 MySQL Community Server - GPL

Copyright (c) 2000, 2020, Oracle and/or its affiliates. All rights reserved.

Oracle is a registered trademark of Oracle Corporation and/or its

affiliates. Other names may be trademarks of their respective

owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql> select @@hostname,@@report_host;

+------------+---------------+

| @@hostname | @@report_host |

+------------+---------------+

| lhrmgr60   | 192.168.68.60 |

+------------+---------------+

1 row in set (0.00 sec)

mysql> SELECT * FROM performance_schema.replication_group_members;

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

| CHANNEL_NAME              | MEMBER_ID                            | MEMBER_HOST   | MEMBER_PORT | MEMBER_STATE | MEMBER_ROLE | MEMBER_VERSION |

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

| group_replication_applier | 408acdb5-80bc-11eb-97a7-0242c0a8443d | 192.168.68.61 |        3306 | ONLINE       | SECONDARY   | 8.0.22         |

| group_replication_applier | 44c693d8-80bb-11eb-b4bb-0242c0a8443c | 192.168.68.60 |        3306 | ONLINE       | PRIMARY     | 8.0.22         |

| group_replication_applier | 9d5c3e3e-80bc-11eb-a0b2-0242c0a8443e | 192.168.68.62 |        3306 | ONLINE       | SECONDARY   | 8.0.22         |

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

3 rows in set (0.01 sec)

mysql> shutdown ;

Query OK, 0 rows affected (0.00 sec)

mysql> select @@hostname,@@report_host;

ERROR 2013 (HY000): Lost connection to MySQL server during query

mysql> select @@hostname,@@report_host;

+------------+---------------+

| @@hostname | @@report_host |

+------------+---------------+

| lhrmgr61   | 192.168.68.61 |

+------------+---------------+

1 row in set (0.00 sec)

mysql> SELECT * FROM performance_schema.replication_group_members;

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

| CHANNEL_NAME              | MEMBER_ID                            | MEMBER_HOST   | MEMBER_PORT | MEMBER_STATE | MEMBER_ROLE | MEMBER_VERSION |

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

| group_replication_applier | 408acdb5-80bc-11eb-97a7-0242c0a8443d | 192.168.68.61 |        3306 | ONLINE       | PRIMARY     | 8.0.22         |

| group_replication_applier | 9d5c3e3e-80bc-11eb-a0b2-0242c0a8443e | 192.168.68.62 |        3306 | ONLINE       | SECONDARY   | 8.0.22         |

+---------------------------+--------------------------------------+---------------+-------------+--------------+-------------+----------------+

2 rows in set (0.00 sec)

[root@lhrmgr60 /]# nslookup rw-mysql-mgr-server-lhr.service.consul

Server:         192.168.68.69

Address:        192.168.68.69#53

Name:   rw-mysql-mgr-server-lhr.service.consul

Address: 192.168.68.61

[root@lhrmgr60 /]# nslookup r-mysql-mgr-server-lhr.service.consul

Server:         192.168.68.69

Address:        192.168.68.69#53

Name:   r-mysql-mgr-server-lhr.service.consul

Address: 192.168.68.62

可以看到，MGR的高可用也运行正常。

About Me

● 本文作者：小麦苗，部分内容整理自网络，若有侵权请联系小麦苗删除

● 本文在个人微信公众号（DB宝）上有同步更新

● QQ群号： 230161599 、618766405，微信群私聊

● 个人QQ号（646634621），微信号（db_bao），注明添加缘由

● 于 2021年3月在西安完成

● 最新修改时间：2021年3月

● 版权所有，欢迎分享本文，转载请保留出处

●小麦苗的微店： https://weidian.com/?userid=793741433

●小麦苗出版的数据库类丛书： http://blog.itpub.net/26736162/viewspace-2142121/

●小麦苗OCP、OCM、高可用、DBA学习班（Oracle、MySQL、NoSQL）： http://blog.itpub.net/26736162/viewspace-2148098/

●数据库笔试面试题库及解答： https://mp.weixin.qq.com/s/Vm5PqNcDcITkOr9cQg6T7w

使用微信客户端扫描下面的二维码来关注小麦苗的微信公众号（DB宝）及QQ群（DBA宝典）、添加小麦苗微信，学习最实用的数据库技术。

【DB宝45】MySQL高可用之MGR+Consul架构部署的更多相关文章

MySQL高可用方案－PXC环境部署记录
之前梳理了Mysql+Keepalived双主热备高可用操作记录,对于mysql高可用方案,经常用到的的主要有下面三种: 一.基于主从复制的高可用方案:双节点主从 + keepalived 一般来说, ...
mysql高可用集群——MHA架构
目录1.下载2.搭建mha 2.1 系统配置 2.2 架构 2.3 添加ssh公钥信任 2.4 安装mha节点 2.5 manager配置文件 2.6 检查 2.7 启动manager进程 2.8 碰 ...
MySQL高可用之MGR安装测试
Preface We've learned the machenism of MGR yesterday,Let's configurate an environment and have s ...
MySQL高可用之MGR安装测试（续）
Preface I've implemented the Group Replication with three servers yesterday,What a shame it ...
【DB宝42】MySQL高可用架构MHA+ProxySQL实现读写分离和负载均衡
目录一.MHA+ProxySQL架构二.快速搭建MHA环境 2.1 下载MHA镜像 2.2 编辑yml文件,创建MHA相关容器 2.3 安装docker-compose软件(若已安装,可忽略) 2 ...
【DB宝19】在Docker中使用MySQL高可用之MHA
目录一.MHA简介和架构 1.1 MHA简介 1.2 MHA工具包的组成 1.3 MHA架构二.准备MHA环境 2.1 下载MHA镜像 2.2 编辑yml文件,创建MHA相关容器 2.3 安装do ...
032：基于Consul和MGR的MySQL高可用架构
目录一.Consul 1.Consul简介 2.准备环境 3.Consul 安装 4.Consul配置文件 5.Consul 服务检查脚本 6.Consul启动二.MGR搭建 1.MGR配置 2. ...
MySQL高可用架构之MySQL5.7组复制MGR
MySQL高可用架构之MySQL5.7组复制MGR########################################################################### ...
MySQL高可用新玩法之MGR+Consul
前面的文章有提到过利用consul+mha实现mysql的高可用,以及利用consul+sentinel实现redis的高可用,具体的请查看:http://www.cnblogs.com/gomysq ...

随机推荐

项目管理工具看板 All In One
项目管理工具看板 All In One Trello https://trello.com/ 我们来总结一下 Trello 是 Atlassian 旗下公司,所有使用 Trello 的人都将使用 At ...
如何将 js 同步方法转换成异步方法
如何将 js 同步方法转换成异步方法 // promise export const getUserToken = () => new Promise((resolve, reject) =&g ...
STAR 法则
STAR 法则 STAR: Situation, Task, Action, Result 一. 什么是 STAR 法则? STAR法则是情境(situation).任务(task).行动(actio ...
holy shit CSDN
holy shit CSDN 垃圾 CSDN 到处都是垃圾文章, 无人子弟到处都是垃圾广告,看的恶心毫无底线,窃取别人的知识成果,毫无版权意识垃圾爬虫,垃圾小号 ...等等 Google Sea ...
super fast sort algorithm in js
super fast sort algorithm in js sort algorithm Promise.race (return the fast one) Async / Await // c ...
Mybatis高级:Mybatis注解开发单表操作,Mybatis注解开发多表操作,构建sql语句,综合案例学生管理系统使用接口注解方式优化
知识点梳理课堂讲义一.Mybatis注解开发单表操作 *** 1.1 MyBatis的常用注解之前我们在Mapper映射文件中编写的sql语句已经各种配置,其实是比较麻烦的而这几年来注解开发越 ...
Spirng 循环依赖报错：Requested bean is currently in creation: Is there an unresolvable circular reference?
1:前言最近在项目中遇到了一次循环依赖报错的问题,虽然解决的很快,但是有些不明白的地方,特此记录. 在此我把 bean 的结构和注入方式单独拎出来进行演示 1.1:报错提示 1.2:错误日志 Ex ...
vmware-install.pl 如何安装？
首先在虚拟机上安装vnware-tools工具,如图(工具为vmware workstation): 成功但是系统屏幕大小并没有适应虚拟机,所以下边这行提示很重要. 打开左侧边栏的VMware ...
C++多文件结构和预编译命令
下面随笔将给出C++多文件结构和预编译命令细节. 多文件结构和编译预处理命令 c++程序的一般组织结构一个工程可以划分多个源文件类声明文件(.h文件) 类实现文件(.cpp文件) 类的使用文件(m ...
ASP.NET Core重复读取Request.Body
//HttpContext context.Request.EnableRewind(); //创建缓冲区存放Request.Body的内容,从而允许反复读取Request.Body的Stream u ...

【DB宝45】MySQL高可用之MGR+Consul架构部署
