GPUImage API文档之GPUImageContext类

　　GPUImageContext类，提供OpenGL ES基本环境，我们一般不会用到，所以讲的很简单。

　　属性

　　@property(readonly, nonatomic) dispatch_queue_t contextQueue

　　说明：创建一个context线程

　　描述：_contextQueue = dispatch_queue_create("com.sunsetlakesoftware.GPUImage.openGLESContextQueue", NULL);



　　@property(readwrite, retain, nonatomic) GLProgram *currentShaderProgram

　　说明：当前着色器program



　　@property(readonly, retain, nonatomic) EAGLContext *context

　　说明：opengl es绘制环境，管理上下文

　　方法

　　　　+ (void *)contextKey

　　　　说明：设置当前context的线程标识符，全局静态变量。

　　

　　　　+ (GPUImageContext *)sharedImageProcessingContext

　　　　说明：创建一个全局的GPUImageContext对象的单例。

　　　　+ (dispatch_queue_t)sharedContextQueue

　　　　说明：创建一个context queue单例

　　　　+ (GPUImageFramebufferCache *)sharedFramebufferCache

　　　　说明：创建一个GPUFramebufferCache单例

　　　　　

　　　　- (void)useAsCurrentContext

　　　　说明：使用当前context

　　　　+ (void)setActiveShaderProgram:(GLProgram *)shaderProgram;

　　　　- (void)setContextShaderProgram:(GLProgram *)shaderProgram;

　　　　+ (GLint)maximumTextureSizeForThisDevice;

　　　　+ (GLint)maximumTextureUnitsForThisDevice;

　　　　+ (GLint)maximumVaryingVectorsForThisDevice;

　　　　+ (BOOL)deviceSupportsOpenGLESExtension:(NSString *)extension;

　　　　+ (BOOL)deviceSupportsRedTextures;

　　　　+ (BOOL)deviceSupportsFramebufferReads;

　　　　+ (CGSize)sizeThatFitsWithinATextureForSize:(CGSize)inputSize;

　　　　- (void)presentBufferForDisplay;

　　　　- (GLProgram *)programForVertexShaderString:(NSString *)vertexShaderString fragmentShaderString:(NSString *)fragmentShaderString;

　　　　- (void)useSharegroup:(EAGLSharegroup *)sharegroup;

　　　　+ (BOOL)supportsFastTextureUpload;

完整代码

#import "GLProgram.h"
#import "GPUImageFramebuffer.h"
#import "GPUImageFramebufferCache.h"

#define GPUImageRotationSwapsWidthAndHeight(rotation) ((rotation) == kGPUImageRotateLeft || (rotation) == kGPUImageRotateRight || (rotation) == kGPUImageRotateRightFlipVertical || (rotation) == kGPUImageRotateRightFlipHorizontal)

typedef enum { kGPUImageNoRotation, kGPUImageRotateLeft, kGPUImageRotateRight, kGPUImageFlipVertical, kGPUImageFlipHorizonal, kGPUImageRotateRightFlipVertical, kGPUImageRotateRightFlipHorizontal, kGPUImageRotate180 } GPUImageRotationMode;

@interface GPUImageContext : NSObject

@property(readonly, nonatomic) dispatch_queue_t contextQueue;
@property(readwrite, retain, nonatomic) GLProgram *currentShaderProgram;
@property(readonly, retain, nonatomic) EAGLContext *context;
@property(readonly) CVOpenGLESTextureCacheRef coreVideoTextureCache;
@property(readonly) GPUImageFramebufferCache *framebufferCache;

+ (void *)contextKey;
+ (GPUImageContext *)sharedImageProcessingContext;
+ (dispatch_queue_t)sharedContextQueue;
+ (GPUImageFramebufferCache *)sharedFramebufferCache;
+ (void)useImageProcessingContext;
- (void)useAsCurrentContext;
+ (void)setActiveShaderProgram:(GLProgram *)shaderProgram;
- (void)setContextShaderProgram:(GLProgram *)shaderProgram;
+ (GLint)maximumTextureSizeForThisDevice;
+ (GLint)maximumTextureUnitsForThisDevice;
+ (GLint)maximumVaryingVectorsForThisDevice;
+ (BOOL)deviceSupportsOpenGLESExtension:(NSString *)extension;
+ (BOOL)deviceSupportsRedTextures;
+ (BOOL)deviceSupportsFramebufferReads;
+ (CGSize)sizeThatFitsWithinATextureForSize:(CGSize)inputSize;

- (void)presentBufferForDisplay;
- (GLProgram *)programForVertexShaderString:(NSString *)vertexShaderString fragmentShaderString:(NSString *)fragmentShaderString;

- (void)useSharegroup:(EAGLSharegroup *)sharegroup;

// Manage fast texture upload
+ (BOOL)supportsFastTextureUpload;

@end

@protocol GPUImageInput <NSObject>
- (void)newFrameReadyAtTime:(CMTime)frameTime atIndex:(NSInteger)textureIndex;
- (void)setInputFramebuffer:(GPUImageFramebuffer *)newInputFramebuffer atIndex:(NSInteger)textureIndex;
- (NSInteger)nextAvailableTextureIndex;
- (void)setInputSize:(CGSize)newSize atIndex:(NSInteger)textureIndex;
- (void)setInputRotation:(GPUImageRotationMode)newInputRotation atIndex:(NSInteger)textureIndex;
- (CGSize)maximumOutputSize;
- (void)endProcessing;
- (BOOL)shouldIgnoreUpdatesToThisTarget;
- (BOOL)enabled;
- (BOOL)wantsMonochromeInput;
- (void)setCurrentlyReceivingMonochromeInput:(BOOL)newValue;
@end

#import "GPUImageContext.h"
#import <OpenGLES/EAGLDrawable.h>
#import <AVFoundation/AVFoundation.h>

#define MAXSHADERPROGRAMSALLOWEDINCACHE 40

@interface GPUImageContext()
{
    NSMutableDictionary *shaderProgramCache;
    NSMutableArray *shaderProgramUsageHistory;
    EAGLSharegroup *_sharegroup;
}

@end

@implementation GPUImageContext

@synthesize context = _context;
@synthesize currentShaderProgram = _currentShaderProgram;
@synthesize contextQueue = _contextQueue;
@synthesize coreVideoTextureCache = _coreVideoTextureCache;
@synthesize framebufferCache = _framebufferCache;

static void *openGLESContextQueueKey;

- (id)init;
{
    if (!(self = [super init]))
    {
        return nil;
    }

    openGLESContextQueueKey = &openGLESContextQueueKey;
    _contextQueue = dispatch_queue_create("com.sunsetlakesoftware.GPUImage.openGLESContextQueue", NULL);

#if OS_OBJECT_USE_OBJC
    dispatch_queue_set_specific(_contextQueue, openGLESContextQueueKey, (__bridge void *)self, NULL);
#endif
    shaderProgramCache = [[NSMutableDictionary alloc] init];
    shaderProgramUsageHistory = [[NSMutableArray alloc] init];

    return self;
}

+ (void *)contextKey {
    return openGLESContextQueueKey;
}

// Based on Colin Wheeler's example here: http://cocoasamurai.blogspot.com/2011/04/singletons-your-doing-them-wrong.html
+ (GPUImageContext *)sharedImageProcessingContext;
{
    static dispatch_once_t pred;
    static GPUImageContext *sharedImageProcessingContext = nil;

    dispatch_once(&pred, ^{
        sharedImageProcessingContext = [[[self class] alloc] init];
    });
    return sharedImageProcessingContext;
}

+ (dispatch_queue_t)sharedContextQueue;
{
    return [[self sharedImageProcessingContext] contextQueue];
}

+ (GPUImageFramebufferCache *)sharedFramebufferCache;
{
    return [[self sharedImageProcessingContext] framebufferCache];
}

+ (void)useImageProcessingContext;
{
    [[GPUImageContext sharedImageProcessingContext] useAsCurrentContext];
}

- (void)useAsCurrentContext;
{
    EAGLContext *imageProcessingContext = [self context];
    if ([EAGLContext currentContext] != imageProcessingContext)
    {
        [EAGLContext setCurrentContext:imageProcessingContext];
    }
}

+ (void)setActiveShaderProgram:(GLProgram *)shaderProgram;
{
    GPUImageContext *sharedContext = [GPUImageContext sharedImageProcessingContext];
    [sharedContext setContextShaderProgram:shaderProgram];
}

- (void)setContextShaderProgram:(GLProgram *)shaderProgram;
{
    EAGLContext *imageProcessingContext = [self context];
    if ([EAGLContext currentContext] != imageProcessingContext)
    {
        [EAGLContext setCurrentContext:imageProcessingContext];
    }

    if (self.currentShaderProgram != shaderProgram)
    {
        self.currentShaderProgram = shaderProgram;
        [shaderProgram use];
    }
}

+ (GLint)maximumTextureSizeForThisDevice;
{
    static dispatch_once_t pred;
    static GLint maxTextureSize = ;

    dispatch_once(&pred, ^{
        [self useImageProcessingContext];
        glGetIntegerv(GL_MAX_TEXTURE_SIZE, &maxTextureSize);
    });

    return maxTextureSize;
}

+ (GLint)maximumTextureUnitsForThisDevice;
{
    static dispatch_once_t pred;
    static GLint maxTextureUnits = ;

    dispatch_once(&pred, ^{
        [self useImageProcessingContext];
        glGetIntegerv(GL_MAX_TEXTURE_IMAGE_UNITS, &maxTextureUnits);
    });

    return maxTextureUnits;
}

+ (GLint)maximumVaryingVectorsForThisDevice;
{
    static dispatch_once_t pred;
    static GLint maxVaryingVectors = ;

    dispatch_once(&pred, ^{
        [self useImageProcessingContext];
        glGetIntegerv(GL_MAX_VARYING_VECTORS, &maxVaryingVectors);
    });

    return maxVaryingVectors;
}

+ (BOOL)deviceSupportsOpenGLESExtension:(NSString *)extension;
{
    static dispatch_once_t pred;
    static NSArray *extensionNames = nil;

    // Cache extensions for later quick reference, since this won't change for a given device
    dispatch_once(&pred, ^{
        [GPUImageContext useImageProcessingContext];
        NSString *extensionsString = [NSString stringWithCString:(const char *)glGetString(GL_EXTENSIONS) encoding:NSASCIIStringEncoding];
        extensionNames = [extensionsString componentsSeparatedByString:@" "];
    });

    return [extensionNames containsObject:extension];
}

// http://www.khronos.org/registry/gles/extensions/EXT/EXT_texture_rg.txt

+ (BOOL)deviceSupportsRedTextures;
{
    static dispatch_once_t pred;
    static BOOL supportsRedTextures = NO;

    dispatch_once(&pred, ^{
        supportsRedTextures = [GPUImageContext deviceSupportsOpenGLESExtension:@"GL_EXT_texture_rg"];
    });

    return supportsRedTextures;
}

+ (BOOL)deviceSupportsFramebufferReads;
{
    static dispatch_once_t pred;
    static BOOL supportsFramebufferReads = NO;

    dispatch_once(&pred, ^{
        supportsFramebufferReads = [GPUImageContext deviceSupportsOpenGLESExtension:@"GL_EXT_shader_framebuffer_fetch"];
    });

    return supportsFramebufferReads;
}

+ (CGSize)sizeThatFitsWithinATextureForSize:(CGSize)inputSize;
{
    GLint maxTextureSize = [self maximumTextureSizeForThisDevice];
    if ( (inputSize.width < maxTextureSize) && (inputSize.height < maxTextureSize) )
    {
        return inputSize;
    }

    CGSize adjustedSize;
    if (inputSize.width > inputSize.height)
    {
        adjustedSize.width = (CGFloat)maxTextureSize;
        adjustedSize.height = ((CGFloat)maxTextureSize / inputSize.width) * inputSize.height;
    }
    else
    {
        adjustedSize.height = (CGFloat)maxTextureSize;
        adjustedSize.width = ((CGFloat)maxTextureSize / inputSize.height) * inputSize.width;
    }

    return adjustedSize;
}

- (void)presentBufferForDisplay;
{
    [self.context presentRenderbuffer:GL_RENDERBUFFER];
}

- (GLProgram *)programForVertexShaderString:(NSString *)vertexShaderString fragmentShaderString:(NSString *)fragmentShaderString;
{
    NSString *lookupKeyForShaderProgram = [NSString stringWithFormat:@"V: %@ - F: %@", vertexShaderString, fragmentShaderString];
    GLProgram *programFromCache = [shaderProgramCache objectForKey:lookupKeyForShaderProgram];

    if (programFromCache == nil)
    {
        programFromCache = [[GLProgram alloc] initWithVertexShaderString:vertexShaderString fragmentShaderString:fragmentShaderString];
        [shaderProgramCache setObject:programFromCache forKey:lookupKeyForShaderProgram];
//        [shaderProgramUsageHistory addObject:lookupKeyForShaderProgram];
//        if ([shaderProgramUsageHistory count] >= MAXSHADERPROGRAMSALLOWEDINCACHE)
//        {
//            for (NSUInteger currentShaderProgramRemovedFromCache = 0; currentShaderProgramRemovedFromCache < 10; currentShaderProgramRemovedFromCache++)
//            {
//                NSString *shaderProgramToRemoveFromCache = [shaderProgramUsageHistory objectAtIndex:0];
//                [shaderProgramUsageHistory removeObjectAtIndex:0];
//                [shaderProgramCache removeObjectForKey:shaderProgramToRemoveFromCache];
//            }
//        }
    }

    return programFromCache;
}

- (void)useSharegroup:(EAGLSharegroup *)sharegroup;
{
    NSAssert(_context == nil, @"Unable to use a share group when the context has already been created. Call this method before you use the context for the first time.");

    _sharegroup = sharegroup;
}

- (EAGLContext *)createContext;
{
    EAGLContext *context = [[EAGLContext alloc] initWithAPI:kEAGLRenderingAPIOpenGLES2 sharegroup:_sharegroup];
    NSAssert(context != nil, @"Unable to create an OpenGL ES 2.0 context. The GPUImage framework requires OpenGL ES 2.0 support to work.");
    return context;
}

#pragma mark -
#pragma mark Manage fast texture upload

+ (BOOL)supportsFastTextureUpload;
{
#if TARGET_IPHONE_SIMULATOR
    return NO;
#else

#pragma clang diagnostic push
#pragma clang diagnostic ignored "-Wtautological-pointer-compare"
    return (CVOpenGLESTextureCacheCreate != NULL);
#pragma clang diagnostic pop

#endif
}

#pragma mark -
#pragma mark Accessors

- (EAGLContext *)context;
{
    if (_context == nil)
    {
        _context = [self createContext];
        [EAGLContext setCurrentContext:_context];

        // Set up a few global settings for the image processing pipeline
        glDisable(GL_DEPTH_TEST);
    }

    return _context;
}

- (CVOpenGLESTextureCacheRef)coreVideoTextureCache;
{
    if (_coreVideoTextureCache == NULL)
    {
#if defined(__IPHONE_6_0)
        CVReturn err = CVOpenGLESTextureCacheCreate(kCFAllocatorDefault, NULL, [self context], NULL, &_coreVideoTextureCache);
#else
        CVReturn err = CVOpenGLESTextureCacheCreate(kCFAllocatorDefault, NULL, (__bridge void *)[self context], NULL, &_coreVideoTextureCache);
#endif

        if (err)
        {
            NSAssert(NO, @"Error at CVOpenGLESTextureCacheCreate %d", err);
        }

    }

    return _coreVideoTextureCache;
}

- (GPUImageFramebufferCache *)framebufferCache;
{
    if (_framebufferCache == nil)
    {
        _framebufferCache = [[GPUImageFramebufferCache alloc] init];
    }

    return _framebufferCache;
}

@end
