在 MacOS 中使用 multipass 安装 microk8s 环境

Multipass & MicroK8s 介绍

What is Kubernetes?

Kubernetes clusters host containerised applications in a reliable and scalable way. Having DevOps in mind, Kubernetes makes maintenance tasks such as upgrades dead simple.

What is Multipass?

Multipass is a lightweight VM manager for Linux, Windows and macOS. It’s designed for developers who want a fresh Ubuntu environment with a single command. It uses KVM on Linux, Hyper-V on Windows and HyperKit on macOS to run the VM with minimal overhead. It can also use VirtualBox on Windows and macOS. Multipass will fetch images for you and keep them up to date.

What is MicroK8s?

MicroK8s is a CNCF certified upstream Kubernetes deployment that runs entirely on your workstation or edge device. Being a snap it runs all Kubernetes services natively (i.e. no virtual machines) while packing the entire set of libraries and binaries needed. Installation is limited by how fast you can download a couple of hundred megabytes and the removal of MicroK8s leaves nothing behind.

参考：Install MicroK8s on Windows using Multipass

安装 multipass & microk8s

安装 multipass 服务

brew search multipass

brew cask info multipass

brew cask install multipass

multipass version

通过 multipass 安装和启动 microk8s 环境

multipass launch --name microk8s-vm --mem 4G --disk 40G

multipass list

multipass stop microk8s-vm

multipass delete microk8s-vm

multipass purge

在虚机中安装 microk8s 服务

multipass exec microk8s-vm -- sudo snap install microk8s --classic

multipass exec microk8s-vm -- sudo iptables -P FORWARD ACCEPT

查看 microk8s 的 snap 包信息，比如版本信息

 multipass exec microk8s-vm -- sudo snap info microk8s

增加账号访问权限，简化操作

# 默认 ubuntu 账号无权限操作集群，均需要 sudo

# 可将 ubuntu 账号加入 microk8s 用户组以便简化访问

multipass exec microk8s-vm -- sudo usermod -a -G microk8s ubuntu

multipass exec microk8s-vm -- sudo sudo chown -f -R ubuntu ~/.kube

增加访问公钥，简化操作

# 在 ~/.ssh/authorized_keys 增加自己的公钥，则可方便的进行SSH登录

multipass shell microk8s-vm

ssh ubuntu@192.168.64.2

查看磁盘空间

multipass exec microk8s-vm -- df -kh

查看 kubeconfig 配置

multipass exec microk8s-vm -- /snap/bin/microk8s.config

在 kubeconfig 中可以找到集群信息，可登录查看

server: https://192.168.64.2:16443

username: admin

password: xxx

增加 DNS 插件，必须安装，多处依赖使用

multipass exec microk8s-vm -- /snap/bin/microk8s.enable dns

multipass exec microk8s-vm -- /snap/bin/microk8s.enable dashboard

尝试访问 Grafana 地址

https://192.168.64.2:16443/api/v1/namespaces/kube-system/services/monitoring-grafana/proxy

安装 Dashboard UI

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl apply -f https://raw.githubusercontent.com/kubernetes/dashboard/v2.0.0/aio/deploy/recommended.yaml

使用 Bearer Token 进行鉴权访问

# 为安全考虑，Dashboard UI 需要使用 Bearer Token 进行鉴权访问，使用如下命令获取 Token

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl -n kube-system get secret | grep default-token | cut -d " " -f1

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl -n kube-system describe secret default-token-qqt75

访问 Dashboard UI

https://192.168.64.2:16443/api/v1/namespaces/kubernetes-dashboard/services/https:kubernetes-dashboard:/proxy/

查看集群组件状态

multipass exec microk8s-vm -- /snap/bin/microk8s.status

可通过指定配置文件进行访问

# 把kubeconfig保存至本地 /Users/xxx/.kube/microk8s-vm.yml，则可通过指定配置文件进行访问

kubectl --insecure-skip-tls-verify --kubeconfig="/Users/xxx/.kube/microk8s-vm.yml" get pods --all-namespaces

# 把kubeconfig保存至本地 ~/.kube/config，则可通过指定配置文件进行访问

kubectl --insecure-skip-tls-verify get pods --all-namespaces

安装 registry 组件


# The MicroK8s registry will not be enabled by default, so needs run the following to enable it.

multipass exec microk8s-vm -- /snap/bin/microk8s.enable registry

查看集群内组件状态

multipass exec microk8s-vm -- /snap/bin/microk8s.status | grep enabled

参考：在 MacOS 中使用 multipass 安装 microk8s 环境

部署业务应用

业务应用 Demo 代码

urban-iptable-management # 简单的IP地址查询服务，服务自治，无外部依赖

urban-district-management # 简单的省市区查询服务，服务自治，无外部依赖

urban-traffic-management # 简单的模拟服务间调用，依赖 district 服务查询城市信息

urban-gateway-management # 模拟API网关，将访问转发至其他服务

Github Repo：https://github.com/gaochundong/urbanboot

本地 docker image 构建

cd urbanboot

docker build -t urban-iptable-management-app:latest --file ./urban-iptable-management/docker/Dockerfile .

docker build -t urban-district-management-app:latest --file ./urban-district-management/docker/Dockerfile .

docker build -t urban-traffic-management-app:latest --file ./urban-traffic-management/docker/Dockerfile .

docker build -t urban-gateway-management-app:latest --file ./urban-gateway-management/docker/Dockerfile .

删除无用镜像

docker images

docker rmi --force $(docker images | grep "^<none>" | awk '{print $3}')

docker images

保存本地镜像至文件

# Save one or more images to a tar archive

docker save -o urban-iptable-management-app.tar urban-iptable-management-app:latest

docker save -o urban-district-management-app.tar urban-district-management-app:latest

docker save -o urban-traffic-management-app.tar urban-traffic-management-app:latest

docker save -o urban-gateway-management-app.tar urban-gateway-management-app:latest

参考：Container Runtimes Part 3: High-Level Runtimes

拷贝镜像文件至 microk8s 机器

scp ./urban-iptable-management-app.tar ubuntu@192.168.64.2:/tmp

scp ./urban-district-management-app.tar ubuntu@192.168.64.2:/tmp

scp ./urban-traffic-management-app.tar ubuntu@192.168.64.2:/tmp

scp ./urban-gateway-management-app.tar ubuntu@192.168.64.2:/tmp

安装镜像至 registry

multipass exec microk8s-vm -- /snap/bin/microk8s.ctr namespaces list

multipass exec microk8s-vm -- /snap/bin/microk8s.ctr images list -q

multipass exec microk8s-vm -- /snap/bin/microk8s.ctr images import /tmp/urban-iptable-management-app.tar

multipass exec microk8s-vm -- /snap/bin/microk8s.ctr images import /tmp/urban-district-management-app.tar

multipass exec microk8s-vm -- /snap/bin/microk8s.ctr images import /tmp/urban-traffic-management-app.tar

multipass exec microk8s-vm -- /snap/bin/microk8s.ctr images import /tmp/urban-gateway-management-app.tar

multipass exec microk8s-vm -- /snap/bin/microk8s.ctr images list -q | grep urban

删除镜像


multipass exec microk8s-vm -- /snap/bin/microk8s.ctr images remove docker.io/library/urban-iptable-management-app:latest

multipass exec microk8s-vm -- /snap/bin/microk8s.ctr images remove docker.io/library/urban-district-management-app:latest

multipass exec microk8s-vm -- /snap/bin/microk8s.ctr images remove docker.io/library/urban-traffic-management-app:latest

multipass exec microk8s-vm -- /snap/bin/microk8s.ctr images remove docker.io/library/urban-gateway-management-app:latest

在部署文件中配置镜像位置


# 替换deployment.yaml文件中的image路径

/Users/xxx/g/github/urbanboot/urban-district-management/kubernetes/deployment.yaml

创建 Namespace

kubectl --insecure-skip-tls-verify create namespace urbanboot

部署应用

kubectl --insecure-skip-tls-verify apply -f /Users/xxx/g/github/urbanboot/urban-iptable-management/kubernetes/deployment.yaml -n urbanboot

kubectl --insecure-skip-tls-verify apply -f /Users/xxx/g/github/urbanboot/urban-district-management/kubernetes/deployment.yaml -n urbanboot

kubectl --insecure-skip-tls-verify apply -f /Users/xxx/g/github/urbanboot/urban-traffic-management/kubernetes/deployment.yaml -n urbanboot

kubectl --insecure-skip-tls-verify apply -f /Users/xxx/g/github/urbanboot/urban-gateway-management/kubernetes/deployment.yaml -n urbanboot

查看部署

kubectl --insecure-skip-tls-verify get deployments -n urbanboot

kubectl --insecure-skip-tls-verify get pods -n urbanboot

删除部署，会自动删除 Pods

kubectl --insecure-skip-tls-verify delete deployment urban-iptable-management-app -n urbanboot

kubectl --insecure-skip-tls-verify delete deployment urban-district-management-app -n urbanboot

kubectl --insecure-skip-tls-verify delete deployment urban-traffic-management-app -n urbanboot

kubectl --insecure-skip-tls-verify delete deployment urban-gateway-management-app -n urbanboot

参考：Build apps locally and Deploy on MicroK8s

创建 Service

kubectl --insecure-skip-tls-verify get services -n urbanboot

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl expose -h

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl expose deployment urban-iptable-management-app --type=ClusterIP --port=7200 --name=urban-iptable-management-app -n urbanboot

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl expose deployment urban-iptable-management-app --type=NodePort --port=7200 --name=urban-iptable-management-nodeport -n urbanboot

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl expose deployment urban-district-management-app --type=ClusterIP --port=7200 --name=urban-district-management-app -n urbanboot

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl expose deployment urban-district-management-app --type=NodePort --port=7200 --name=urban-district-management-nodeport -n urbanboot

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl expose deployment urban-traffic-management-app --type=ClusterIP --port=7200 --name=urban-traffic-management-app -n urbanboot

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl expose deployment urban-traffic-management-app --type=NodePort --port=7200 --name=urban-traffic-management-nodeport -n urbanboot

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl expose deployment urban-gateway-management-app --type=ClusterIP --port=7200 --name=urban-gateway-management-app -n urbanboot

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl expose deployment urban-gateway-management-app --type=NodePort --port=7200 --name=urban-gateway-management-nodeport -n urbanboot

multipass exec microk8s-vm -- /snap/bin/microk8s.kubectl expose deployment urban-traffic-management-app --type=LoadBalancer --port=7200 --name=urban-traffic-management-loadbalancer -n urbanboot

参考：Kubernetes NodePort vs LoadBalancer vs Ingress? When should I use what?
The big downside is that each service you expose with a LoadBalancer will get its own IP address, and you have to pay for a LoadBalancer per exposed service, which can get expensive!

使用配置文件创建 Service


kubectl --insecure-skip-tls-verify expose -f /Users/xxx/g/github/urbanboot/urban-traffic-management/kubernetes/service.yaml -n urbanboot

kubectl --insecure-skip-tls-verify expose -f /Users/xxx/g/github/urbanboot/urban-traffic-management/kubernetes/nodeport.yaml -n urbanboot

删除 Service

kubectl --insecure-skip-tls-verify delete service urban-iptable-management-app -n urbanboot

kubectl --insecure-skip-tls-verify delete service urban-iptable-management-nodeport -n urbanboot

kubectl --insecure-skip-tls-verify delete service urban-district-management-app -n urbanboot

kubectl --insecure-skip-tls-verify delete service urban-district-management-nodeport -n urbanboot

kubectl --insecure-skip-tls-verify delete service urban-traffic-management-app -n urbanboot

kubectl --insecure-skip-tls-verify delete service urban-traffic-management-nodeport -n urbanboot

kubectl --insecure-skip-tls-verify delete service urban-gateway-management-app -n urbanboot

kubectl --insecure-skip-tls-verify delete service urban-gateway-management-nodeport -n urbanboot

查一下 TCP 端口监听

multipass exec microk8s-vm -- netstat -nl -t

查看部署事件，按照时间排序

kubectl --insecure-skip-tls-verify get events -n urbanboot --sort-by=.metadata.creationTimestamp

查看 Pod 日志

kubectl --insecure-skip-tls-verify get pods -n urbanboot

kubectl --insecure-skip-tls-verify describe pod urban-traffic-management-app-58d7578547-p277h -n urbanboot

kubectl --insecure-skip-tls-verify logs urban-traffic-management-app-58d7578547-p277h -n urbanboot

kubectl --insecure-skip-tls-verify logs urban-traffic-management-app-58d7578547-p277h -n urbanboot --tail=20

查看 Endpoint 信息

# Spring Cloud Kubernetes 会通过 API 查询 Endpoints

kubectl --insecure-skip-tls-verify get services -n urbanboot

kubectl --insecure-skip-tls-verify get endpoints -n urbanboot

kubectl --insecure-skip-tls-verify get all --all-namespaces

kubectl --insecure-skip-tls-verify get all -n urbanboot

kubectl --insecure-skip-tls-verify describe services urban-traffic-management-nodeport -n urbanboot

kubectl --insecure-skip-tls-verify describe services urban-traffic-management-app -n urbanboot

访问 NodePort 端口

curl -s http://192.168.64.2:30211

curl -s http://192.168.64.2:30211 -i

curl -s http://192.168.64.2:30211 -v

登录 Pod 环境

kubectl --insecure-skip-tls-verify exec -it urban-traffic-management-app-58d7578547-p277h -n urbanboot -- /bin/bash

查看 Java 进程

java -version

env | grep JAVA

ps -ef|grep java
