java 高效递归查询树 find_in_set 处理递归树

建表语句

DROP TABLE IF EXISTS `sys_dept`;
CREATE TABLE `sys_dept` (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT '部门id',
  `parent_id` bigint(20) DEFAULT '0' COMMENT '父部门id',
  `ancestors` varchar(256) DEFAULT '' COMMENT '祖级列表',
  `dept_name` varchar(64) DEFAULT '' COMMENT '部门名称',
  `order_num` int(4) DEFAULT '0' COMMENT '显示顺序',
  `status` tinyint(1) DEFAULT '0' COMMENT '部门状态（0正常 1停用）',
  `create_time` datetime DEFAULT NULL COMMENT '创建时间',
  `create_user_id` bigint(20) DEFAULT NULL COMMENT '创建人id',
  `create_user_name` varchar(64) DEFAULT NULL COMMENT '创建人姓名',
  `update_time` datetime DEFAULT NULL COMMENT '修改时间',
  `update_user_id` bigint(20) DEFAULT NULL COMMENT '修改人id',
  `update_user_name` varchar(64) DEFAULT NULL COMMENT '修改人姓名',
  PRIMARY KEY (`id`) USING BTREE,
  UNIQUE KEY `uk_dept_name` (`parent_id`,`dept_name`) USING BTREE
) ENGINE=InnoDB AUTO_INCREMENT=10 DEFAULT CHARSET=utf8 COMMENT='部门表';

-- ----------------------------
-- Records of sys_dept
-- ----------------------------
BEGIN;
INSERT INTO `sys_dept` VALUES (1, 0, '0', 'XX科技', 0, 0, '2021-10-09 10:31:47', 1, '系统管理员', NULL, NULL, NULL);
INSERT INTO `sys_dept` VALUES (2, 1, '0,1', '商务部', 3, 0, '2021-12-06 15:33:20', 1, '系统管理员', '2021-12-06 15:58:30', 1234, '管理');
INSERT INTO `sys_dept` VALUES (3, 1, '0,1', 'XX关务部', 4, 0, '2021-12-06 15:37:01', 1, '系统管理员', '2021-12-06 15:40:15', 1, '系统管理员');
INSERT INTO `sys_dept` VALUES (4, 1, '0,1', 'XX货主', 6, 0, '2021-12-06 15:38:34', 1, '系统管理员', '2021-12-06 17:17:27', 1, '系统管理员');
INSERT INTO `sys_dept` VALUES (5, 1, '0,1', '技术部', 1, 0, '2021-12-06 15:39:22', 1, '系统管理员', '2021-12-06 15:57:48', 1234, '管理');
INSERT INTO `sys_dept` VALUES (6, 4, '0,1,4', '货主-A', 1, 0, '2021-12-06 16:15:26', 1234, '小A', '2021-12-06 17:16:33', 1, '系统管理员');
INSERT INTO `sys_dept` VALUES (7, 4, '0,1,4', '货主-B', 2, 0, '2021-12-06 16:15:39', 1234, '小A', '2021-12-06 17:17:37', 1, '系统管理员');
INSERT INTO `sys_dept` VALUES (8, 6, '0,1,4,6', '1', 11, 0, '2022-03-16 10:27:28', 1, '系统管理员', '2022-03-16 10:27:37', 1, '系统管理员');
INSERT INTO `sys_dept` VALUES (9, 8, '0,1,4,6,8', '111111', 0, 0, '2022-03-16 10:27:45', 1, '系统管理员', NULL, NULL, NULL);
COMMIT;

新增

@Data
@ApiModel(value = "部门编辑对象", description = "部门编辑请求对象")
public class DeptEditRequest {
    @ApiModelProperty(value = "主键id", example = "-1")
    @DecimalMin(value = "1", message = "角色id最小为1")
    private Long id;

    @ApiModelProperty(value = "父部门id", example = "-1")
    @NotNull(message = "上级部门" + HibernateConstant.NOT_NULL)
    @JsonProperty("parent_id")
    private Long parentId;

    @ApiModelProperty(value = "部门名称", example = "IT部")
    @NotBlank(message = "部门名称" + HibernateConstant.NOT_NULL)
    @JsonProperty("dept_name")
    private String deptName;

    @ApiModelProperty(value = "显示顺序", example = "0")
    @NotNull(message = "显示" + HibernateConstant.NOT_NULL)
    @JsonProperty("order_num")
    private Integer orderNum;

    @ApiModelProperty(value = "部门状态（0正常 1停用）", example = "0")
    @Min(value = 0, message = "部门状态（0正常 1停用）")
    @Max(value = 1, message = "部门状态（0正常 1停用）")
    private byte status;
}

    @ApiOperation("部门添加")
    @PostMapping("add")
    public JsonData add(
            @RequestBody DeptAddRequest request
    ) {
        return deptService.add(request);
    }

    @Override
    public JsonData add(DeptAddRequest request) {
        DeptEditRequest deptEditRequest = new DeptEditRequest();
        BeanUtils.copyProperties(request, deptEditRequest);
        //同级部门下，部门名称重复
        checkDeptNameUnique(deptEditRequest);
        DeptDO deptDO = new DeptDO();
        deptDO.setDeptName(request.getDeptName());
        deptDO.setParentId(request.getParentId());
        deptDO.setStatus(request.getStatus());
        deptDO.setOrderNum(request.getOrderNum());
        deptDO.setCreateTime(CommonUtil.getCurrentDate());
        deptDO.setCreateUserId(CommonUtil.getCurrentUserId());
        deptDO.setCreateUserName(CommonUtil.getCurrentUserName());
        //检查上级部门状态
        checkParentDeptState(deptDO);
        int rows = deptMapper.add(deptDO);
        if (rows > 0) {
            log.info("部门添加，rows:{}，添加成功:{}", rows, deptDO);
            return JsonData.buildAddSuccess();
        }
        return JsonData.buildError("添加失败");
    }

    /**
     * 部门名称唯一值
     *
     * @param request
     */
    private void checkDeptNameUnique(DeptEditRequest request) {
        List<DeptDO> deptList = deptMapper.selectList(
                new LambdaQueryWrapper<DeptDO>()
                        .eq(DeptDO::getDeptName, request.getDeptName())
                        .eq(DeptDO::getParentId, request.getParentId())
        );
        for (DeptDO deptDO : deptList) {
            if (deptDO.getId() != request.getId()) {
                throw new BizException(500, "部门已存在");
            }
        }
    }

    /**
     * 检查上级部门状态
     *
     * @param dept 部门对象
     */
    private void checkParentDeptState(DeptDO dept) {
        DeptDO deptDO = deptMapper.selectOne(
                new LambdaQueryWrapper<DeptDO>()
                        .eq(DeptDO::getId, dept.getParentId())
        );
        if (deptDO == null) {
            throw new BizException(500, "上级部门不存在");
        }
        if (1 == deptDO.getStatus()) {
            throw new BizException(500, "上级部门已停用，不允许新增");
        }
        dept.setAncestors(deptDO.getAncestors() + "," + dept.getParentId());
    }

编辑

@Data
@ApiModel(value = "部门编辑对象", description = "部门编辑请求对象")
public class DeptEditRequest {
    @ApiModelProperty(value = "主键id", example = "-1")
    @DecimalMin(value = "1", message = "角色id最小为1")
    private Long id;

    @ApiModelProperty(value = "父部门id", example = "-1")
    @NotNull(message = "上级部门" + HibernateConstant.NOT_NULL)
    @JsonProperty("parent_id")
    private Long parentId;

    @ApiModelProperty(value = "部门名称", example = "IT部")
    @NotBlank(message = "部门名称" + HibernateConstant.NOT_NULL)
    @JsonProperty("dept_name")
    private String deptName;

    @ApiModelProperty(value = "显示顺序", example = "0")
    @NotNull(message = "显示" + HibernateConstant.NOT_NULL)
    @JsonProperty("order_num")
    private Integer orderNum;

    @ApiModelProperty(value = "部门状态（0正常 1停用）", example = "0")
    @Min(value = 0, message = "部门状态（0正常 1停用）")
    @Max(value = 1, message = "部门状态（0正常 1停用）")
    private byte status;
}

    @ApiOperation("部门修改")
    @PostMapping("edit")
    public JsonData edit(
            @RequestBody DeptEditRequest request
    ) {
        if (request.getId() == 1) {
            throw new BizException(500, "不允许操作系统默认部门");
        }
        return deptService.edit(request);
    }

    @Override
    @Transactional
    public JsonData edit(DeptEditRequest request) {
        DeptDO deptDO = new DeptDO();
        BeanUtils.copyProperties(request, deptDO);
        //同级部门下，部门名称重复
        checkDeptNameUnique(request);
        //检查上级部门状态
        checkParentDeptState(deptDO);
        //上级部门不能是自己
        checkParentDept(request);
        //父级对象
        DeptDO parentDept = deptMapper.selectOne(
                new LambdaQueryWrapper<DeptDO>()
                        .eq(DeptDO::getId, deptDO.getParentId())
        );
        if (parentDept == null) {
            throw new BizException(500, "上级部门不存在");
        }
        DeptDO oldDept = deptMapper.selectOne(
                new LambdaQueryWrapper<DeptDO>()
                        .eq(DeptDO::getId, deptDO.getId())
        );
        if (oldDept == null) {
            throw new BizException(500, "记录不存在，请稍后重试");
        }
        String newAncestors = parentDept.getAncestors() + "," + parentDept.getId();
        String oldAncestors = oldDept.getAncestors();
        deptDO.setAncestors(newAncestors);
        byte oldState = oldDept.getStatus();
        int rows = deptMapper.updateById(deptDO);
        if (rows > 0) {
            log.info("部门修改，rows:{},修改成功:{}", rows, deptDO);
            //递归处理子部门状态
            if (oldState != deptDO.getStatus()) {
                updateChildDeptState(deptDO, newAncestors, oldAncestors);
            }
            return JsonData.buildEditSuccess();
        }
        return JsonData.buildError("修改失败");
    }

    /**
     * 部门名称唯一值
     *
     * @param request
     */
    private void checkDeptNameUnique(DeptEditRequest request) {
        List<DeptDO> deptList = deptMapper.selectList(
                new LambdaQueryWrapper<DeptDO>()
                        .eq(DeptDO::getDeptName, request.getDeptName())
                        .eq(DeptDO::getParentId, request.getParentId())
        );
        for (DeptDO deptDO : deptList) {
            if (deptDO.getId() != request.getId()) {
                throw new BizException(500, "部门已存在");
            }
        }
    }

    /**
     * 检查上级部门状态
     *
     * @param dept 部门对象
     */
    private void checkParentDeptState(DeptDO dept) {
        DeptDO deptDO = deptMapper.selectOne(
                new LambdaQueryWrapper<DeptDO>()
                        .eq(DeptDO::getId, dept.getParentId())
        );
        if (deptDO == null) {
            throw new BizException(500, "上级部门不存在");
        }
        if (1 == deptDO.getStatus()) {
            throw new BizException(500, "上级部门已停用，不允许新增");
        }
        dept.setAncestors(deptDO.getAncestors() + "," + dept.getParentId());
    }

    /**
     * 上级部门不能是自己
     *
     * @param request
     */
    private void checkParentDept(DeptEditRequest request) {
        if (request.getId().equals(request.getParentId())) {
            throw new BizException(500, "上级部门不能是自己");
        }
    }

    /**
     * 处理子部门状态
     *
     * @param deptDO       部门对象
     * @param newAncestors 新的父ID集合
     * @param oldAncestors 旧的父ID集合
     */
    private void updateChildDeptState(DeptDO deptDO, String newAncestors, String oldAncestors) {
        deptMapper.batchUpdateChildDeptState(deptDO.getId(), deptDO.getStatus());
        //找所有子部门
        List<DeptDO> deptList = deptMapper.selectChildrenDeptById(deptDO.getId());
        for (DeptDO dpt : deptList) {
            dpt.setAncestors(dpt.getAncestors().replaceFirst(oldAncestors, newAncestors));
            deptMapper.updateById(dpt);
        }
    }

    /**
     * 批量更新子部门状态
     *
     * @param id    部门id
     * @param state 状态
     * @return
     */
    int batchUpdateChildDeptState(
            @Param("id") Long id,
            @Param("state") Byte state
    );

    <!-- 批量更新子部门状态 -->
    <update id="batchUpdateChildDeptState">
        UPDATE
            sys_dept
        SET
            `status`=#{state}
        WHERE ancestors LIKE CONCAT('%',#{id},'%')
    </update>

    /**
     * 根据id找所有子部门
     *
     * @param id
     * @return
     */
    List<DeptDO> selectChildrenDeptById(@Param("id") Long id);

    <!-- 根据id找所有子部门 -->
    <select id="selectChildrenDeptById" resultMap="BaseResultMap">
        SELECT
            id,
            parent_id,
            ancestors,
            dept_name,
            order_num,
            `status`,
            create_time,
            create_user_id,
            create_user_name,
            update_time,
            update_user_id,
            update_user_name
        FROM
            sys_dept
        WHERE
            FIND_IN_SET(#{id},ancestors)
    </select>

删除

    @ApiOperation("部门删除")
    @GetMapping("remove")
    public JsonData remove(
            @ApiParam(value = "部门id", required = true) @RequestParam(value = "id", required = true) Long id
    ) {
        if (id == 1) {
            throw new BizException(500, "不允许操作系统默认部门");
        }
        return deptService.remove(id);
    }

    @Override
    public JsonData remove(Long id) {
        int rows = deptMapper.deleteById(id);
        if (rows > 0) {
            log.info("部门删除，rows:{},删除成功:{}", rows, id);
            //递归删除子部门
            removeChildDept(id);
            return JsonData.buildRemoveSuccess();
        }
        return JsonData.buildError("部门删除失败");
    }

    /**
     * 删除子部门
     *
     * @param parentId
     */
    private void removeChildDept(Long parentId) {
        List<DeptDO> deptList = deptMapper.selectList(
                new LambdaQueryWrapper<DeptDO>()
                        .eq(DeptDO::getParentId, parentId)
        );
        for (DeptDO deptDO : deptList) {
            deptMapper.deleteById(deptDO.getId());
            removeChildDept(deptDO.getId());
        }
    }

递归树

@Data
@ApiModel(value = "DeptTreeVo对象", description = "部门树对象信息")
public class DeptTreeVo {
    @ApiModelProperty("节点id")
    @JsonSerialize(using = ToStringSerializer.class)
    private Long id;

    @ApiModelProperty("节点名称")
    private String label;

    @ApiModelProperty("子节点")
    @JsonInclude(JsonInclude.Include.NON_EMPTY)
    private List<DeptTreeVo> children;
}

    @ApiOperation("部门树")
    @GetMapping("deptTree")
    public JsonData<List<DeptTreeVo>> deptTree() {
        return deptService.deptTree();
    }

    private static final ThreadPoolExecutor THREAD_POOL_EXECUTOR = new ThreadPoolExecutor(
            APS * 2,
            APS * 4,
            KEEP_ALIVE_TIME,
            TimeUnit.SECONDS,
            new LinkedBlockingDeque<>(256),
            new ThreadFactoryBuilder().setNameFormat("部门-pool-%d").build(),
            new ThreadPoolExecutor.CallerRunsPolicy()
    );

    @Override
    public JsonData<List<DeptTreeVo>> deptTree() {
        LambdaQueryWrapper<DeptDO> wrapper = new LambdaQueryWrapper<DeptDO>();
        wrapper.orderByAsc(DeptDO::getParentId, DeptDO::getOrderNum);
        List<DeptDO> deptList = deptMapper.selectList(wrapper);
        return buildDeptTree(deptList);
    }

    /**
     * 构建前端需要构建树结构
     *
     * @param deptList 部门集合
     * @return
     */
    private JsonData<List<DeptTreeVo>> buildDeptTree(List<DeptDO> deptList) {
        List<DeptTreeVo> deptTreeList = new ArrayList<>();
        List<DeptDO> rootDeptList = deptList.stream().filter(obj -> 1 == obj.getId()).collect(Collectors.toList());
        CountDownLatch latch = new CountDownLatch(rootDeptList.size());
        for (DeptDO deptDO : rootDeptList) {
            THREAD_POOL_EXECUTOR.execute(() -> {
                DeptTreeVo vo = new DeptTreeVo();
                vo.setId(deptDO.getId());
                vo.setLabel(deptDO.getDeptName());
                buildChildrentDeptTree(deptList, deptDO.getId(), vo);
                deptTreeList.add(vo);
                latch.countDown();
            });
        }
        try {
            latch.await();
        } catch (InterruptedException e) {
            log.error("构建部门树结构线程报错:{}", e);
        }
        return JsonData.buildSuccess(deptTreeList);
    }

    /**
     * 构建子部门树
     *
     * @param deptList 部门集合
     * @param parentId 父ID
     * @param vo       部门树
     */
    private void buildChildrentDeptTree(List<DeptDO> deptList, Long parentId, DeptTreeVo vo) {
        List<DeptDO> childList = deptList.stream().filter(obj -> parentId == obj.getParentId()).collect(Collectors.toList());
        List<DeptTreeVo> childDeptTreeList = new ArrayList<>();
        for (DeptDO deptDO : childList) {
            DeptTreeVo dtv = new DeptTreeVo();
            dtv.setId(deptDO.getId());
            dtv.setLabel(deptDO.getDeptName());
            buildChildrentDeptTree(deptList, deptDO.getId(), dtv);
            childDeptTreeList.add(dtv);
        }
        vo.setChildren(childDeptTreeList);
    }

@Data
@TableName("sys_dept")
@ApiModel(value = "SysDeptDO对象", description = "部门表")
public class DeptDO implements Serializable {

    private static final long serialVersionUID = 1L;

    @ApiModelProperty(value = "部门id")
    @TableId(value = "id", type = IdType.AUTO)
    private Long id;

    @ApiModelProperty(value = "父部门id")
    private Long parentId;

    @ApiModelProperty(value = "祖级列表")
    private String ancestors;

    @ApiModelProperty(value = "部门名称")
    private String deptName;

    @ApiModelProperty(value = "显示顺序")
    private Integer orderNum;

    @ApiModelProperty(value = "部门状态（0正常 1停用）")
    private byte status;

    @ApiModelProperty(value = "创建时间")
    @TableField(value = "create_time", fill = FieldFill.INSERT)
    private Date createTime;

    @ApiModelProperty(value = "创建人id")
    @TableField(value = "create_user_id", fill = FieldFill.INSERT)
    private Long createUserId;

    @ApiModelProperty(value = "创建人姓名")
    @TableField(value = "create_user_name", fill = FieldFill.INSERT)
    private String createUserName;

    @ApiModelProperty(value = "修改时间")
    @TableField(value = "update_time", fill = FieldFill.UPDATE)
    private Date updateTime;

    @ApiModelProperty(value = "修改人id")
    @TableField(value = "update_user_id", fill = FieldFill.UPDATE)
    private Long updateUserId;

    @ApiModelProperty(value = "修改人姓名")
    @TableField(value = "update_user_name", fill = FieldFill.UPDATE)
    private String updateUserName;
}

树通用工具类

    /**
     * 递归深度
     */
    private static final int DEPTH = 20;

    /**
     * 集合转树
     * @param treeList  集合
     * @param rootId 父节点
     * @param <T>
     */
    public static <T extends TreeNode<T>>  void list2Tree(List<T> treeList,Long rootId){
        if (CollUtil.isEmpty(treeList)){
            return;
        }
        if (rootId==null){
            throw new Exception("根节点不能为空");
        }
        List<T> rootList = getRoot(treeList, rootId);
        if (CollUtil.isNotEmpty(rootList)){
            List<T> result = new LinkedList<>();
            rootList.stream().forEach(t-> result.add(getChildNode(t,0,treeList)));
            treeList.clear();
            treeList.addAll(rootList);
        }
    }

    private static <T extends TreeNode<T>> List<T> getRoot(List<T> treeList,Long rootId){
        return treeList.stream().filter(t->Objects.equals(t.rootId(),rootId)).collect(Collectors.toList());
    }

    private static  <T extends TreeNode<T>> T getChildNode(T t,int depthCount,List<T> treeList){
        if (depthCount>DEPTH){
            throw new Exception("超过递归限制");
        }
        List<T> childList = treeList.stream().filter(item -> Objects.equals(item.rootId(), t.nodeId())).collect(Collectors.toList());
        if (CollUtil.isNotEmpty(childList)){
            int tempCount = ++depthCount;
            childList.stream().forEach(child->t.childList().add(getChildNode(child,tempCount,treeList)));
        }
        return t;
    }

import java.util.List;

public interface TreeNode<T> {
    /**
     * 节点id
     * @return
     */
    Long nodeId();

    /**
     * 父节点
     * @return
     */
    Long rootId();

    /**
     * 子级列表
     * @return
     */
    List<T> childList();
}

/**
 * @description: 树VO
 * @author: alex
 * @create: 2024-03-16 15:46
 */
@Data
public class XxxxVO implements TreeNode<XxxxVO > {

    @ApiModelProperty("主键id")
    private Long id;

    @ApiModelProperty("父ID")
    private Long parentId;

    @ApiModelProperty("编码")
    private String code;

    @ApiModelProperty("名称")
    private String name;

    private List<XxxxVO> subList = new LinkedList<>();

    @ApiModelProperty("是否尾节点")
    private boolean isLastNode;

    @Override
    public Long nodeId() {
        return getId();
    }

    @Override
    public Long rootId() {
        return getParentId();
    }

    @Override
    public List<XxxxVO> childList() {
        return this.subList;
    }

    public boolean isLastNode() {
        return this.subList.size() == 0;
    }
}

使用

//数据库中查询出来列表
List<XxxxVO> treeList=new LinkedList<>();
//转换树
TreeUtil.listToTree(treeList,0L);
