JMeter性能测试5.0时代之-多维度的图形化HTML报告

快速入门

1.确认基本配置

  • 在jmeter.properties或者user.properties确认如下配置项：

  • jmeter.save.saveservice.bytes = true
    jmeter.save.saveservice.label = true
    jmeter.save.saveservice.latency = true
    jmeter.save.saveservice.response_code = true
    jmeter.save.saveservice.response_message = true
    jmeter.save.saveservice.successful = true
    jmeter.save.saveservice.thread_counts = true
    jmeter.save.saveservice.thread_name = true
    jmeter.save.saveservice.time = true
    # the timestamp format must include the time and should include the date.
    # For example the default, which is milliseconds since the epoch:
    jmeter.save.saveservice.timestamp_format = ms
    # Or the following would also be suitable
    jmeter.save.saveservice.timestamp_format = yyyy/MM/dd HH:mm:ss
    jmeter.save.saveservice.assertion_results_failure_message = true

  • #针对Response的编码处理，需要修改统一为UTF-8，避免部分Reponse乱码问题
  • #由于HTML报告的需要，针对jmeter生成的jtl文件所包含的数据需要做新的配置，以满足测试需求

    #修改生成的jtl文件为xml格式存储数据

  • sampleresult.default.encoding=UTF-8
    jmeter.save.saveservice.output_format=xml

  • jmeter.save.saveservice.response_code #为HTTP响应代码（404、502之类）

    jmeter.save.saveservice.response_data#为Reponse详细信息

  • 重点来啦修改\apache-jmeter-5.0\extras\build文件

1、修改build主要是修改报告模板，将之前的jmeter-results-detail-report_21.xsl或者jmeter-results-report_21.xsl替换成本文提到的jmeter.results.shanhe.me.xsl(见下面)

2、

<?xml version="1.0" encoding="UTF-8"?>

<xsl:stylesheet xmlns:xsl="http://www.w3.org/1999/XSL/Transform" version="1.0">

    <xsl:output method="html" indent="no" encoding="UTF-8" doctype-public="-//W3C//DTD HTML 4.01 Transitional//EN" doctype-system="http://www.w3.org/TR/html4/loose.dtd"/>

    <xsl:strip-space elements="*"/>

    <xsl:template match="/testResults">

        <html lang="en">

        <head>

            <meta name="Author" content="shanhe.me"/>

            <title>JMeter Test Results</title>

            <style type="text/css"><![CDATA[

                * { margin: 0; padding: 0 }

                html, body { width: 100%; height: 100%; background: #b4b4b4; font-size: 12px }

                table { border: none; border-collapse: collapse; table-layout: fixed }

                td { vertical-align: baseline; font-size: 12px }

                #left-panel { position: absolute; left: 0; top: 0; bottom: 0; width: 300px; overflow: auto; background: #dee4ea }


                #left-panel li.success { color: #565b60 }

                #left-panel li.failure { color: red }

                #left-panel li { list-style: none; color: black; cursor: pointer }


                #left-panel div { line-height: 20px; background-position: 25px 3px; background-repeat: no-repeat; padding: 0 0 0 45px }



                #left-panel div.detail { display: none }

                #right-panel { position: absolute; right: 0; top: 0; bottom: 0; left: 301px; overflow: auto; background: white }



                #right-panel .data { line-height: 19px; white-space: nowrap }

                #right-panel pre.data { white-space: pre }

                #right-panel tbody.failure { color: red }

                #right-panel td.key { min-width: 108px }

                #right-panel td.delimiter { min-width: 18px }

                #right-panel td.assertion:before { counter-increment: assertion; content: counter(assertion) ". " }

                #right-panel td.assertion { color: black }

                #right-panel .trail { border-top: 1px solid #b4b4b4 }

            ]]></style>

            <script type="text/javascript"><![CDATA[

                var onclick_li = (function() {

                    var last_selected = null;

                    return function(li) {

                        if( last_selected == li )

                            return;

                        if( last_selected )

                            last_selected.className = "";

                        last_selected = li;

                        last_selected.className = "selected";

                        document.getElementById("right-panel").innerHTML = last_selected.firstChild.nextSibling.innerHTML;

                        return false;

                    };

                })();

                var patch_timestamp = function() {

                    var spans = document.getElementsByTagName("span");

                    var len = spans.length;

                    for( var i = 0; i < len; ++i ) {

                        var span = spans[i];

                        if( "patch_timestamp" == span.className )

                            span.innerHTML = new Date( parseInt( span.innerHTML ) );

                    }

                };

                var patch_navigation_class = (function() {

                    var set_class = function(el, flag) {

                        if(el) {

                            el.className += flag ? " success" : " failure";

                        }

                    };

                    var traverse = function(el, group_el, flag) {

                        while(1) {

                            if(el) {

                                if(el.className == 'navigation') {

                                    set_class(group_el, flag);

                                    group_el = el;

                                    flag = true;

                                } else {

                                    var o = el.firstChild;

                                    o = o ? o.className : null;

                                    flag = flag ? (o == 'success') : false;

                                }

                                el = el.nextSibling;

                            } else {

                                set_class(group_el, flag);

                                break;

                            }

                        }

                    };

                    return function() {

                        var o = document.getElementById("result-list");

                        o = o ? o.firstChild : null;

                        if(o)

                            traverse(o, null, true);

                    };

                })();

                window.onload = function() {

                    patch_timestamp();

                    patch_navigation_class();

                    var o = document.getElementById("result-list");

                    o = o ? o.firstChild : null;

                    o = o ? o.nextSibling : null;

                    if(o)

                        onclick_li(o);

                };

            ]]></script>

        </head>

        <body>

            <div id="left-panel">

                <ol id="result-list">

                    <xsl:for-each select="*">

                        <!-- group with the previous sibling -->

                        <xsl:if test="position() = 1 or @tn != preceding-sibling::*[1]/@tn">

                            <li class="navigation">Thread: <xsl:value-of select="@tn"/></li>

                        </xsl:if>

                        <li onclick="return onclick_li(this);">

                            <div>

                                <xsl:attribute name="class">

                                    <xsl:choose>

                                        <xsl:when test="@s = 'true'">success</xsl:when>

                                        <xsl:otherwise>failure</xsl:otherwise>

                                    </xsl:choose>

                                </xsl:attribute>

                                <xsl:value-of select="@lb"/>

                            </div><div class="detail">

                                <div class="group">Sampler</div>

                                <div class="zebra">

                                    <table>

                                        <tr><td class="data key">Thread Name</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@tn"/></td></tr>

                                        <tr><td class="data key">Timestamp</td><td class="data delimiter">:</td><td class="data"><span class="patch_timestamp"><xsl:value-of select="@ts"/></span></td></tr>

                                        <tr><td class="data key">Time</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@t"/> ms</td></tr>

                                        <tr><td class="data key">Latency</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@lt"/> ms</td></tr>

                                        <tr><td class="data key">Bytes</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@by"/></td></tr>

                                        <tr><td class="data key">Sample Count</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@sc"/></td></tr>

                                        <tr><td class="data key">Error Count</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@ec"/></td></tr>

                                        <tr><td class="data key">Response Code</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@rc"/></td></tr>

                                        <tr><td class="data key">Response Message</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@rm"/></td></tr>

                                    </table>

                                </div>

                                <div class="trail"></div>

                                <xsl:if test="count(assertionResult) &gt; 0">

                                    <div class="group">Assertion</div>

                                    <div class="zebra">

                                        <table>

                                            <xsl:for-each select="assertionResult">

                                                <tbody>

                                                    <xsl:attribute name="class">

                                                        <xsl:choose>

                                                            <xsl:when test="failure = 'true'">failure</xsl:when>

                                                            <xsl:when test="error = 'true'">failure</xsl:when>

                                                        </xsl:choose>

                                                    </xsl:attribute>

                                                    <tr><td class="data assertion" colspan="3"><xsl:value-of select="name"/></td></tr>

                                                    <tr><td class="data key">Failure</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="failure"/></td></tr>

                                                    <tr><td class="data key">Error</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="error"/></td></tr>

                                                    <tr><td class="data key">Failure Message</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="failureMessage"/></td></tr>

                                                </tbody>

                                            </xsl:for-each>

                                        </table>

                                    </div>

                                    <div class="trail"></div>

                                </xsl:if>

                                <div class="group">Request</div>

                                <div class="zebra">

                                    <table>

                                        <tr><td class="data key">Method/Url</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="method"/><xsl:text> </xsl:text><xsl:value-of select="java.net.URL"/></pre></td></tr>

                                        <tr><td class="data key">Query String</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="queryString"/></pre></td></tr>

                                        <tr><td class="data key">Cookies</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="cookies"/></pre></td></tr>

                                        <tr><td class="data key">Request Headers</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="requestHeader"/></pre></td></tr>

                                    </table>

                                </div>

                                <div class="trail"></div>

                                <div class="group">Response</div>

                                <div class="zebra">

                                    <table>

                                        <tr><td class="data key">Response Headers</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="responseHeader"/></pre></td></tr>

                                        <tr><td class="data key">Response Data</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="responseData"/></pre></td></tr>

                                        <tr><td class="data key">Response File</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="responseFile"/></pre></td></tr>

                                    </table>

                                </div>

                                <div class="trail"></div>

                            </div>

                        </li>

                    </xsl:for-each>

                </ol>

            </div>

            <div id="right-panel"></div>

        </body>

        </html>

    </xsl:template>

</xsl:stylesheet>

2>    修改(为了方便，直接替换)build.xml文件

<?xml version="1.0" encoding="utf-8"?>

<project name="ant-jmeter-test" default="run" basedir=".">

  <tstamp>

    <format property="time" pattern="yyyyMMddhhmm"/>

  </tstamp>

  <property name="basedirectory" value="D:\Program Files\apache-jmeter-5.0\extras"/>

  <!-- 需要改成自己本地的 Jmeter 目录-->

  <property name="jmeter.home" value="D:\Program Files\apache-jmeter-5.0"/>

  <!-- jmeter生成jtl格式的结果报告的路径-->

  <property name="jmeter.result.jtl.dir" value="${basedirectory}"/>

  <!-- jmeter生成html格式的结果报告的路径-->

  <property name="jmeter.result.html.dir" value="${basedirectory}"/>

  <!-- Name of test (without .jmx) -->

  <property name="test" value="Test"/>

  <!-- 生成的报告的前缀-->

  <property name="ReportName" value="TestReport"/>

  <property name="jmeter.result.jtlName" value="${jmeter.result.jtl.dir}/${test}.jtl"/>

  <property name="jmeter.result.htmlName" value="${jmeter.result.html.dir}/${test}.html"/>

  <path id="xslt.classpath">

    <fileset dir="${jmeter.home}/lib" includes="xalan*.jar"/>

    <fileset dir="${jmeter.home}/lib" includes="serializer*.jar"/>

  </path>

  <target name="run">

    <antcall target="test"/>

    <antcall target="report"/>

  </target>

  <target name="test">

    <taskdef name="jmeter" classname="org.programmerplanet.ant.taskdefs.jmeter.JMeterTask"/>

    <jmeter jmeterhome="${jmeter.home}" resultlog="${jmeter.result.jtlName}">

      <!-- 声明要运行的脚本。"*.jmx"指包含此目录下的所有jmeter脚本-->

      <testplans dir="${basedirectory}" includes="${test}.jmx"/>

    </jmeter>

  </target>

  <target name="report">

    <tstamp>

      <format property="report.datestamp" pattern="yyyy/MM/dd HH:mm"/>

    </tstamp>

    <xslt classpathref="xslt.classpath" force="true" in="${jmeter.result.jtlName}" out="${jmeter.result.htmlName}" style="${jmeter.home}/extras/jmeter.results.shanhe.me.xsl">

      <param name="dateReport" expression="${report.datestamp}"/>

    </xslt>

    <copy todir="${jmeter.result.html.dir}">

      <fileset dir="${jmeter.home}/extras">

        <include name="collapse.png"/>

        <include name="expand.png"/>

      </fileset>

    </copy>

  </target>

</project>


到这里更新设置就完成了，这个改动并不大，主要就是给生成的HTML报告换一个模板，使得生成的HTML报告更加详细

2.生成报告

a. 在压力测试结束时报告

          • 基本命令格式：
            jmeter -n -t <test JMX file> -l <test log file> -e -o <Path to output folder>
          • 样例：

            • java -jar ApacheJMeter.jar -Jjmeter.save.saveservice.output_format=xml  -n -t test.jmx -l test.jtl -e -o report

            b. 使用已有的压力测试CSV日志文件生成报告
            • 基本命令格式：
              jmeter -g <log file> -o <Path to output folder>
            • 样例：
              jmeter -g testLogFile -o ./report
            • 两个样例都会在\apache-jmeter-5.0\bin\output目录下产生如下文件(夹)

            • 用浏览器打开index.html文件，即可查看各种图形化报告:

              注：在3.0版本，由于源码中字符编码的问题，可能会遇到生成的报告中，中文标签展示为乱码的问题

            • bin目录下放待运行脚本，jtl已存在的需要剪切到其他位置，report文件夹测试前要清空（report文件夹是自己创建的保存报告的位置）
            • 参考来源：https://blog.csdn.net/huodoubi/article/details/60956124?utm_source=itdadao&utm_medium=referral
            • 参考来源2：https://blog.csdn.net/qq_34021712/article/details/78697671

jmeter5.0生成html报告 快速入门的更多相关文章

  1. Apache Spark 2.2.0 中文文档 - 快速入门 | ApacheCN

    快速入门 使用 Spark Shell 进行交互式分析 基础 Dataset 上的更多操作 缓存 独立的应用 快速跳转 本教程提供了如何使用 Spark 的快速入门介绍.首先通过运行 Spark 交互 ...

  2. 0基础如何更快速入门Linux系统？学完Linux有哪些就业方向？

    Linux系统是使用Linux内核及开源自由软件组成的一套操作系统,是一种类UNIX系统,其内核在1991年10月5日由林纳斯·托瓦兹首次发布. 它的主要特性:Linux文件一切皆文件.完全开源免费. ...

  3. Spring Boot WebFlux 快速入门实践

    02:WebFlux 快速入门实践 Spring Boot 2.0 spring.io 官网有句醒目的话是: BUILD ANYTHING WITH SPRING BOOT Spring Boot ( ...

  4. Spring Boot 2 快速教程：WebFlux 快速入门（二）

    摘要: 原创出处 https://www.bysocket.com 「公众号:泥瓦匠BYSocket 」欢迎关注和转载,保留摘要,谢谢! 02:WebFlux 快速入门实践 文章工程: JDK 1.8 ...

  5. Spring Boot WebFlux-01——WebFlux 快速入门实践

    第01课:WebFlux 快速入门实践 Spring Boot 2.0 spring.io 官网有句醒目的话是: BUILD ANYTHING WITH SPRING BOOT Spring Boot ...

  6. 【笔记目录2】【jessetalk 】ASP.NET Core快速入门_学习笔记汇总

    当前标签: ASP.NET Core快速入门 共2页: 上一页 1 2  任务27:Middleware管道介绍 GASA 2019-02-12 20:07 阅读:15 评论:0 任务26:dotne ...

  7. Applescript快速入门及OmniFocus每日md报告开发

    本篇主要记录 Applescript 基础语法,以及利用 applescript 生成 omnifocus 每日报告 从 windows 转换到 macos,最近一直在不断折腾,这两天浏览 githu ...

  8. Spark快速入门 - Spark 1.6.0

    Spark快速入门 - Spark 1.6.0 转载请注明出处:http://www.cnblogs.com/BYRans/ 快速入门(Quick Start) 本文简单介绍了Spark的使用方式.首 ...

  9. Spring Boot 2.0 的快速入门（图文教程）

    摘要: 原创出处 https://www.bysocket.com 「公众号:泥瓦匠BYSocket 」欢迎关注和转载,保留摘要,谢谢! Spring Boot 2.0 的快速入门(图文教程) 大家都 ...

随机推荐

  1. March 05th, 2018 Week 10th Monday

    Fortune favors the bold. 勇者天佑. It has been increasingly apparent that courage is the main quality we ...

  2. input reset 重置时间

    经验规律,301毫秒. function autoFormatMoney() { if (!this.value.length) {return} var num = parseFloat(this. ...

  3. 解决Zabbix网页端Get value error: cannot connect to [[192.168.238.139]:10050]: [113] No route to host问题

    在安装配置完zabbix_agentd以后,网页端出现  Get value error: cannot connect to [[192.168.238.139]:10050]: [113] No ...

  4. 图上最短路(Dijkstra, spfa)

    单源最短路径 题目描述 如题,给出一个有向图,请输出从某一点出发到所有点的最短路径长度. 输入输出格式 输入格式: 第一行包含三个整数N.M.S,分别表示点的个数.有向边的个数.出发点的编号. 接下来 ...

  5. centos7 mongodb安装

    参考文档 http://www.runoob.com/mongodb/mongodb-connections.html https://www.cnblogs.com/layezi/p/7290082 ...

  6. P2360 地下城主（BFS）

    感觉这道题还是蛮简单的,不过使使用了4个队列(其实只是一个)emmmmm,还是很好的 #include<iostream> #include<string> #include& ...

  7. TFT1.44显示屏

    下载这个库 普通arduino的接口 链接 UTFT myGLCD(LPH9135,6,5,2,3,4); mega2560的接口连接 UTFT myGLCD(QD_TFT180A,A2,A1,A5, ...

  8. （1） 安卓导入mqtt包基本通信

    参考资料:http://blog.csdn.net/qq_17250009/article/details/52774472 MQTT官网:http://mqtt.org/ MQTT介绍:http:/ ...

  9. hyperledger中文文档学习-4-构建第一个fabric网络

    接下来的操作都将在hyperledge环境安装构建的虚拟机的环境下进行 参考https://hyperledgercn.github.io/hyperledgerDocs/build_network_ ...

  10. day25 Python四个可以实现自省的函数，反射

    python面向对象中的反射:通过字符串的形式操作对象相关的属性.python中的一切事物都是对象(都可以使用反射) 四个可以实现自省的函数 下列方法适用于类和对象(一切皆对象,类本身也是一个对象) ...
